Design
Antenna: Yes
Antenna design: External
Internal: Yes
Antenna direction type: Omni-directional
Antenna gain level (max): 5 dBi
Component for: PC
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 70 °C
Storage relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -10 - 80 °C
Weight & dimensions
Height: 1.6 mm
Width: 65 mm
Depth: 44.5 mm
Network
Bluetooth version: 5.2
Wi-Fi band: Tri-band (2.4 GHz / 5 GHz / 6 GHz)
LAN controller: Intel AX210
Wi-Fi standards: 802.11b, 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Maximum data transfer rate: 2400 Mbit/s
Bluetooth: Yes
WLAN data transfer rates supported: 574, 2402
Networking standards: IEEE 802.11b, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, IEEE 802.11a, IEEE 802.11ax
Security algorithms: WPA3
Wi-Fi: Yes
Spread spectrum method: OFDMA
System requirements
Windows operating systems supported: Windows 10, Windows 11
Packaging content
Bluetooth header cable: Yes
Resource CD: Yes
Mounting brackets included: Yes
Quick installation guide: Yes
Ports & interfaces
Interface: WLAN / Bluetooth
PCI Card form factor: Full-height (low-profile)
Host interface: PCI Express
Connectivity technology: Wireless
Other features
Bracket height: Low-Profile (LP) / Full-Height (FH)
Safety warning
Warnings: The product contains electronic components and should not be disposed of in the regular rubbish bin., Please observe local regulations regarding the disposal of electronic waste., Avoid contact with liquids. If spilled, the product may be damaged.
