Features
Internal memory: 64 MB
Flash memory: 8 MB
Design
Product colour: White
Product type: Tabletop router
LED indicators: LAN, Power, WAN, WLAN
Power
Output voltage: 12 V
Power source type: DC
Output current: 1 A
Security
MAC address filtering: Yes
Filtering: Yes
Security algorithms: WPA2, WPA, WEP, WPA-PSK, WPA2-PSK
Parental control: Yes
IP address filtering: Yes
Guest access: Yes
Firewall: Yes
DMZ support: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Management features
Reset button: Yes
Web-based management: Yes
Wi-Fi Multimedia (WMM)/(WME): Yes
WPS push button: Yes
Weight & dimensions
Height: 27.9 mm
Depth: 134.6 mm
Width: 221 mm
VPN support: PPTP/L2TP/OpenVPN/WireGuard
Network
Ethernet LAN data rates: 100, 10
Ethernet LAN: Yes
Dynamic DNS (DDNS): Yes
Port forwarding: Yes
Port triggering: Yes
Ethernet LAN interface type: Fast Ethernet
Number of guest networks (5 GHz): 1
Wireless radio: Yes
Number of guest networks (2.4 GHz): 1
System requirements
Browser supported: Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0
Mac compatibility: Yes
Mac operating systems supported: MacOS
Windows operating systems supported: Windows NT, Windows 8.1, Windows Vista, Windows XP, Windows 2000, Windows 7, Windows 10, Windows 98SE, Windows 8
Packaging data
Number of products included: 1 pc(s)
Package type: Box
Packaging content
AC adapter included: Yes
Cables included: LAN (RJ-45)
Quick installation guide: Yes
Wireless LAN features
Wi-Fi standards: 802.11a, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), 802.11g, 802.11b
WLAN data transfer rate (second band): 867 Mbit/s
Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
WLAN data transfer rate (first band): 300 Mbit/s
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (max): 867 Mbit/s
Protocols
DHCP client: Yes
DHCP server: Yes
Universal Plug and Play (UPnP): Yes
Ports & interfaces
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 4
USB port: No
Antenna
Antennas quantity: 4
Antenna design: External
Antenna gain level (max): 5 dBi
WAN connection
WAN connection type: RJ-45
DSL WAN: No
3G/4G USB modem compatibility: No
SIM card slot: No
Ethernet WAN: Yes
Mobile network
3G: No
4G: No
5G: No
Safety warning
Warnings: Do not expose the device to water or moisture., Do not expose the device to extreme temperatures., Do not dismantle the unit yourself, there is a risk of electric shock.
