Processor
Processor model: ARM Cortex-A7
Processor frequency: 2 GHz
Processor cores: 4
Design
Product colour: Black
Power
Output voltage: 12 V
AC input voltage: 100 - 240 V
Power consumption (max): 17 W
Power source type: DC
Output current: 1.5 A
AC input frequency: 50/60 Hz
Security
Security algorithms: WPA2, WPA, WPA3
DMZ support: Yes
Firewall security: SPI, DoS
Parental control: Yes
Guest access: Yes
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Management features
OFDMA: Y
Reset button: Yes
WPS push button: Yes
Wireless statistics: Yes
MU-MIMO technology: Yes
Weight & dimensions
Width: 253 mm
Weight: 580 g
Depth: 48.2 mm
Height: 152.5 mm
Network
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
Ethernet LAN interface type: Gigabit Ethernet
Ethernet LAN: Yes
Packaging data
Number of products included: 1 pc(s)
Packaging content
Cables included: LAN (RJ-45)
AC adapter included: Yes
Wireless LAN features
Wi-Fi standards: Wi-Fi 7 (802.11be)
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Maximum data transfer rate (2.4 GHz): 688 Mbit/s
Maximum data transfer rate (5 GHz): 5765 Mbit/s
Static IP: Yes
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Point-to-point protocol over Ethernet (PPPoE): Yes
Protocols
Supported network protocols: IPv4 / IPv6
DHCP client: Yes
DHCP server: Yes
Universal Plug and Play (UPnP): Yes
Ports & interfaces
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 4
Number of Ethernet WAN ports: 1
WAN connection
Ethernet WAN: Yes
WAN connection type: RJ-45
Safety warning
Warnings: Do not expose the device to water or moisture., Do not expose the device to extreme temperatures., Do not dismantle the unit yourself, there is a risk of electric shock.
