Technical details
Sustainability certificates: EAC, CE, RoHS
Sustainability compliance: Yes
Features
UPS topology: Line-Interactive
Surge protection features: Modem, Fax, Network, Telephone
Input frequency: 50/60 Hz
Input operation voltage (max): 290 V
Response time: 4 ms
Surge protection: Yes
Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm
EMI/RFI noise filtering: Yes
Output frequency: 50/60 Hz
Output power: 720 W
Input operation voltage (min): 165 V
Power protection features: Short circuit
Waveform: Sine
Audible alarm(s): Yes
Output power capacity: 1.2 kVA
Heat dissipation: 137 BTU/h
Surge energy rating: 150 J
Output operation voltage (max): 240 V
Automatic Voltage Regulation (AVR): Yes
Output operation voltage (min): 220 V
Design
Form factor: Desktop
Display type: LCD
Product colour: Black
Cable length: 1.5 m
LED indicators: Status, Power, Battery level
Housing material: Plastic
Operational conditions
Storage temperature (T-T): -20 - 50 °C
Storage relative humidity (H-H): 0 - 90%
Operating altitude: 0 - 3000 m
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 90%
Non-operating altitude: 0 - 3000 m
Weight & dimensions
Package width: 158 mm
Width: 166 mm
Depth: 288 mm
Package height: 230 mm
Height: 118 mm
Weight: 8.2 kg
Ports & interfaces
USB port: Yes
Ethernet LAN (RJ-45) ports: 2
AC outlet types: Type F
Modem (RJ-11) ports: 2
AC outlets quantity: 8 AC outlet(s)
USB 2.0 ports quantity: 1
USB port type: USB Type-A
Battery
Typical backup time at half load: 9 min
Number of batteries supported: 2
Battery technology: Sealed Lead Acid (VRLA)
Battery recharge time: 8 h
Replacement battery cartridge: RBP0063
Typical backup time at full load: 2 min
Battery voltage: 230 V
Other features
Number of phases: 1
Logistics data
Harmonized System (HS) code: 8504408590
