Features
Response time: 4 ms
Output voltage Total Harmonic Distortion (THD): 10%
Surge protection features: Fax, Network, Telephone, Modem
Power protection features: Short circuit, Over voltage, Over power, Overload
Input operation voltage (min): 170 V
Waveform: Pure sine
Audible alarm(s): Yes
Input frequency: 50/60 Hz
EMI/RFI noise filtering: Yes
Audible alarm modes: Alarm when on battery, Low battery alarm, Overload alarm
Auto-restart: Yes
Output power: 540 W
Maximum current: 10 A
Input operation voltage (max): 270 V
UPS topology: Standby (Offline)
Surge energy rating: 405 J
Output power capacity: 0.9 kVA
Output frequency: 50/60 Hz
Surge protection: Yes
Design
Housing material: Plastic
Cable length: 1.83 m
Form factor: Tower
Display type: LCD
LED indicators: Operation
Product colour: Black
Operational conditions
Non-operating altitude: 0 - 15000 m
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): 15 - 45 °C
Operating altitude: 0 - 3000 m
Storage relative humidity (H-H): 0 - 95%
Weight & dimensions
Weight: 6.6 kg
Width: 100 mm
Height: 275 mm
Depth: 230 mm
Packaging data
Package width: 195 mm
Package height: 335 mm
Ports & interfaces
Power plug: C14 coupler
AC outlets quantity: 6 AC outlet(s)
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 1
AC outlet types: Type F
Modem (RJ-11) ports: 1
Battery
Battery voltage: 230 V
Battery recharge time: 8 h
Battery technology: Sealed Lead Acid (VRLA)
Typical backup time at half load: 7 min
Typical backup time at full load: 1 min
Number of batteries supported: 1
Compatible operating systems: Windows 7/Vista/XP/2000/Server 2003, Linux
Other features
Interface: USB
Nominal output voltage: 230 V
Nominal input voltage: 165-265 V
Operating temperature (T-T): 32 - 104 °F
Logistics data
Harmonized System (HS) code: 8504408590
Safety warning
Warnings: Do not disassemble the unit housing, there may be a risk of electric shock., Keep away from sources of fire and water., Use the appliance in well-ventilated areas to avoid overheating.
