Features Surge protection features: Modem, Network, Telephone Waveform: Pure sine Response time: 0 ms Efficiency (ECO mode): 95% Output frequency: 50/60 Hz Surge energy rating: 363 J Output power: 900 W EMI/RFI noise filtering: Yes Audible alarm(s): Yes Input power factor: 0.99 Output power capacity: 1 kVA Output operation voltage (max): 240 V Power protection features: Surge protection ECO mode: Yes Maximum current: 4.5 A Input frequency: 50/60 Hz Output operation voltage (min): 208 V Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm Surge protection: Yes UPS topology: Double-conversion (Online) Power factor: 0.9 Input current Total Harmonic Distortion (THD): 3% Crest factor: 3:1 Input operation voltage (max): 300 V Input operation voltage (min): 160 V
Design Form factor: Rackmount/Tower Rack capacity: 2U Cable length: 1.5 m Product colour: Black Display type: LCD Housing material: Metal
Operational conditions Storage relative humidity (H-H): 10 - 90% Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 20 - 90% Storage temperature (T-T): -20 - 50 °C Operating altitude: 0 - 1500 m Non-operating altitude: 0 - 1500 m
Weight & dimensions Weight: 10.4 kg Depth: 430 mm Width: 438 mm Height: 88 mm
Packaging data Package height: 230 mm Package width: 540 mm
Packaging content Cables included: USB cable
Ports & interfaces Ethernet LAN (RJ-45) ports: 1 AC outlets quantity: 8 AC outlet(s) USB 2.0 ports quantity: 1 USB port: Yes Modem (RJ-11) ports: 1 AC outlet types: C13 coupler
Battery Battery voltage: 12 V Charging current: 1.5 A Number of batteries supported: 2 Battery technology: Sealed Lead Acid (VRLA) Replacement battery cartridge: RBP0156 Battery capacity: 9 Ah Typical backup time at full load: 4.6 min Typical backup time at half load: 13.9 min Hot-swap battery: Yes
Logistics data Harmonized System (HS) code: 8504408590
