Technical details
Sustainability certificates: RoHS, CE
Compliance certificates: RoHS, CE
Features
Waveform: Pure sine
Output power capacity: 1.5 kVA
Input operation voltage (max): 300 V
Power protection features: Short circuit, Overload, Input fuse
UPS topology: Double-conversion (Online)
Input frequency: 50/60 Hz
Noise level: 45 dB
Crest factor: 3:1
EMI/RFI noise filtering: Yes
Output voltage Total Harmonic Distortion (THD): 5%
Audible alarm modes: Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
Output operation voltage (max): 240 V
Input operation voltage (min): 190 V
Surge protection: Yes
Output power factor: 0.9
Output operation voltage (min): 208 V
Surge energy rating: 363 J
Input power factor: 0.99
Efficiency (ECO mode): 95%
Output frequency: 50/60 Hz
Audible alarm(s): Yes
Emergency Power Off (EPO): Yes
Maximum current: 9 A
Output power: 1350 W
Design
Built-in fan: Yes
Rack capacity: 2U
Form factor: Rackmount/Tower
Display type: LCD
Cable length: 1.5 m
Product colour: Black
Housing material: Metal
Operational conditions
Operating altitude: 0 - 1500 m
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 10 - 90%
Non-operating altitude: 0 - 1500 m
Operating relative humidity (H-H): 20 - 90%
Storage temperature (T-T): -20 - 50 °C
Weight & dimensions
Height: 88 mm
Width: 438 mm
Package height: 230 mm
Package width: 540 mm
Weight: 13.8 kg
Depth: 430 mm
Packaging data
Cables included: USB cable
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
AC outlet types: C13 coupler
AC outlets quantity: 8 AC outlet(s)
USB port: Yes
Power plug: C14 coupler
Emergency Power Off (EPO) connector: Yes
Battery
Charging current: 1.5 A
Typical backup time at full load: 5.3 min
Number of batteries supported: 4
Battery recharge time: 4 h
Replacement battery cartridge: BPSE48V40ART2U
Typical backup time at half load: 15.3 min
Battery voltage: 48 V
Logistics data
Harmonized System (HS) code: 8504408590
