Features Maximum current: 9 A Waveform: Pure sine EMI/RFI noise filtering: Yes Output frequency: 50/60 Hz Input power factor: 0.99 Output voltage Total Harmonic Distortion (THD): 5% Audible alarm modes: Fault, Low battery alarm, Overload alarm Input frequency: 50/60 Hz Surge energy rating: 363 J UPS topology: Double-conversion (Online) ECO mode: Yes Surge protection: Yes Power protection features: Overload Power factor: 0.9 Input operation voltage (max): 300 V Input operation voltage (min): 190 V Output power capacity: 2 kVA Audible alarm(s): Yes Efficiency (ECO mode): 95% Crest factor: 3:1 Output power: 1800 W Noise level: 45 dB Response time: 0 ms
Design Display type: LCD Housing material: Metal Cable length: 1.5 m Rack capacity: 2U Product colour: Black Form factor: Rackmount/Tower
Operational conditions Non-operating altitude: 0 - 1500 m Operating relative humidity (H-H): 20 - 90% Operating temperature (T-T): 0 - 40 °C Storage temperature (T-T): -20 - 50 °C Storage relative humidity (H-H): 10 - 90% Operating altitude: 0 - 1500 m
Weight & dimensions Height: 88 mm Depth: 430 mm Weight: 17.1 kg Width: 438 mm
Packaging data Package height: 230 mm Package width: 540 mm
Packaging content Cables included: USB cable
Ports & interfaces USB port: Yes Modem (RJ-11) ports: 1 Power plug: C14 coupler AC outlet types: C13 coupler AC outlets quantity: 8 AC outlet(s) Ethernet LAN (RJ-45) ports: 1
Battery Typical backup time at half load: 13.1 min Charging current: 1.5 A Typical backup time at full load: 3.8 min Hot-swap battery: Yes Battery voltage: 12 V Battery technology: Sealed Lead Acid (VRLA) Battery capacity: 9 Ah Number of batteries supported: 4
Logistics data Harmonized System (HS) code: 8504408590
Safety warning Warnings: Keep away from sources of fire and water., Use the appliance in well-ventilated areas to avoid overheating., Do not disassemble the unit housing, there may be a risk of electric shock.
