Features
Output operation voltage (max): 240 V
Output operation voltage (min): 208 V
Surge energy rating: 363 J
Power factor: 0.9
EMI/RFI noise filtering: Yes
Output voltage regulation: 1%
Audible alarm modes: Battery replacement, Low battery alarm, Overload alarm, Fault, Alarm when on battery
Maximum current: 9 A
ECO mode: Yes
UPS topology: Double-conversion (Online)
Output power capacity: 2 kVA
Input frequency: 50/60 Hz
Output frequency regulation: 0.5 Hz
Output voltage Total Harmonic Distortion (THD): 5%
Output power factor: 0.9
Crest factor: 3:1
Surge protection: Yes
Efficiency (ECO mode): 95%
Waveform: Pure sine
Input power factor: 0.99
Heat dissipation: 682 BTU/h
Input operation voltage (max): 300 V
Emergency Power Off (EPO): Yes
Output frequency: 50/60 Hz
Input operation voltage (min): 190 V
Output power: 1800 W
Response time: 0 ms
Power protection features: Overload
Audible alarm(s): Yes
Design
Control type: Buttons
Built-in fan: Yes
Display type: LCD
Product colour: Black
Cable length: 1.5 m
Rack capacity: 2U
Cooling type: Active
Housing material: Metal
Form factor: Rackmount/Tower
Operational conditions
Non-operating altitude: 0 - 1500 m
Storage temperature (T-T): -20 - 50 °C
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 5 - 95%
Operating altitude: 0 - 1500 m
Storage relative humidity (H-H): -20 - 50%
Weight & dimensions
Height: 88 mm
Weight: 19.2 kg
Depth: 430 mm
Width: 438 mm
Packaging data
Package height: 230 mm
Package width: 540 mm
Packaging content
Rack mount kit: Yes
Cables included: Input power cable, USB cable
Batteries included: Yes
Manual: Yes
Certification: CE, EAC
Certificates
Compliance certificates: RoHS, CE, EAC
Ports & interfaces
Emergency Power Off (EPO) connector: Yes
AC outlet types: C13 coupler
USB port type: USB Type-B
Serial interface: Yes
Serial interface type: RS-232
RS-232 ports: 1
Ethernet LAN (RJ-45) ports: 1
Serial ports quantity: 1
Modem (RJ-11) ports: 1
USB port: Yes
AC outlets quantity: 8 AC outlet(s)
Power plug: Type F
Battery
Battery life (max): 5 year(s)
Charging current: 1.5 A
Replacement battery cartridge: RBP0157
Hot-swap battery: Yes
Number of batteries included: 2 pc(s)
Number of batteries supported: 3
Battery capacity: 9 Ah
Battery technology: Sealed Lead Acid (VRLA)
Battery voltage: 48 V
Typical backup time at half load: 13.1 min
Battery recharge time: 4 h
Typical backup time at full load: 3.8 min
Logistics data
Harmonized System (HS) code: 8504408590
Safety warning
Warnings: Do not disassemble the unit housing, there may be a risk of electric shock., Keep away from sources of fire and water., Use the appliance in well-ventilated areas to avoid overheating.
