Features Output operation voltage (min): 230 V Output power capacity: 1 kVA UPS topology: Line-Interactive Output operation voltage (max): 230 V Output power: 600 W Power factor: 0.6 Power protection features: Overload Automatic Voltage Regulation (AVR): Yes Input operation voltage (min): 165 V EMI/RFI noise filtering: Yes Response time: 4 ms Output frequency: 50/60 Hz Surge protection: Yes Waveform: Sine Audible alarm(s): Yes Audible alarm modes: Fault, Low battery alarm, Overload alarm Input frequency: 50/60 Hz Surge energy rating: 810 J Input operation voltage (max): 271 V Maximum current: 10 A Certification: CE, EAC, RCM
Design Product colour: Silver LED indicators: Operation Form factor: Rackmount Housing material: Metal Rack capacity: 1U Cable length: 1.83 m Display type: LCD
Operational conditions Storage temperature (T-T): -15 - 45 °C Operating temperature (T-T): 0 - 40 °C Storage relative humidity (H-H): 0 - 95% Operating altitude: 0 - 3000 m Operating relative humidity (H-H): 0 - 95% Non-operating altitude: 0 - 15000 m
Weight & dimensions Depth: 389 mm Package height: 158 mm Width: 433 mm Weight: 13.7 kg Height: 44 mm Package width: 545 mm
Packaging data Cables included: USB cable
Ports & interfaces AC outlet types: C13 coupler Modem (RJ-11) ports: 1 AC outlets quantity: 6 AC outlet(s) Ethernet LAN (RJ-45) ports: 1 USB port: Yes Power plug: C14 coupler Serial ports quantity: 1
Battery Battery technology: Sealed Lead Acid (VRLA) Typical backup time at half load: 14 min Hot-swap battery: Yes Typical backup time at full load: 3.5 min Number of batteries supported: 1 Battery recharge time: 8 h
Logistics data Harmonized System (HS) code: 8504408590
