Features Response time: 4 ms Surge protection features: Network, Fax, Modem, Digital Subscriber Line (DSL), Telephone Output power: 360 W Power protection features: Overload Maximum current: 10 A EMI/RFI noise filtering: Yes Surge protection: Yes Output frequency: 50/60 Hz Power factor: 0.6 Surge energy rating: 405 J Output operation voltage (max): 230 V Input frequency: 50/60 Hz Input operation voltage (max): 271 V Audible alarm(s): Yes Waveform: Sine Output operation voltage (min): 230 V Output power capacity: 0.6 kVA Audible alarm modes: Low battery alarm, Overload alarm UPS topology: Line-Interactive Input operation voltage (min): 165 V Automatic Voltage Regulation (AVR): Yes Certification: CE, EAC, RCM
Design LED indicators: Operation Rack capacity: 1U Cable length: 1.83 m Product colour: Silver Form factor: Rackmount Housing material: Metal Display type: LCD
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 0 - 95% Storage relative humidity (H-H): 0 - 95% Operating altitude: 0 - 3000 m Storage temperature (T-T): -15 - 45 °C Non-operating altitude: 0 - 15000 m
Weight & dimensions Package width: 530 mm Weight: 7.8 kg Package height: 155 mm Depth: 235 mm Height: 44 mm Width: 433 mm
Packaging data Cables included: USB cable
Ports & interfaces Ethernet LAN (RJ-45) ports: 1 AC outlets quantity: 6 AC outlet(s) Serial ports quantity: 1 Modem (RJ-11) ports: 1 USB port: Yes Power plug: C14 coupler AC outlet types: C13 coupler
Battery Number of batteries supported: 1 Battery technology: Sealed Lead Acid (VRLA) Typical backup time at half load: 13 min Typical backup time at full load: 4 min Battery recharge time: 8 h Hot-swap battery: Yes
Logistics data Harmonized System (HS) code: 8504408590
