Features
Input operation voltage (max): 288 V
Input operation voltage (min): 159 V
Heat dissipation: 47.4 BTU/h
Output power factor: 1
Emergency Power Off (EPO): Yes
Waveform: Pure sine
Number of input phases: 1
Output frequency: 50/60 Hz
Output operation voltage (max): 240 V
UPS topology: Line-Interactive
Management protocols: SNMP/HTTP
Number of output phases: 1
Maximum current: 10 A
Surge energy rating: 2430 J
Automatic Voltage Regulation (AVR): Yes
Output operation voltage (min): 220 V
Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm
Power Factor Correction (PFC) type: Active
Audible alarm(s): Yes
Response time: 4 ms
Output power capacity: 1 kVA
Power protection features: Overload
Web-based management: Yes
EMI/RFI noise filtering: Yes
Surge protection features: Network
Noise level: 52.5 dB
Input frequency: 50/60 Hz
Output power: 1000 W
Surge protection: Yes
Design
Built-in fan: Yes
Control type: Buttons
LED indicators: Status, Power, Fault
Housing material: Metal
Form factor: Rackmount/Tower
Product colour: Black
Cable length: 1.8 m
Display type: LCD
Rack capacity: 2U
Cooling type: Active
Operational conditions
Non-operating altitude: 0 - 15000 m
Operating altitude: 0 - 3000 m
Storage relative humidity (H-H): 0 - 95%
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -15 - 45 °C
Weight & dimensions
Weight: 22.4 kg
Depth: 412 mm
Width: 433 mm
Height: 86.5 mm
Packaging data
Package height: 275 mm
Package width: 560 mm
Packaging content
Rack mount kit: Yes
Manual: Yes
Cables included: Serial, USB cable
Certificates
Compliance certificates: Federal Communications Commission (FCC), VCCI, UL, UKCA, RCM, RoHS, CE
Ports & interfaces
Serial interface: Yes
AC outlet types: C13 coupler
Emergency Power Off (EPO) connector: Yes
Serial interface type: RS-232
Power plug: C14 coupler
USB 2.0 ports quantity: 1
AC outlets quantity: 10 AC outlet(s)
Ethernet LAN (RJ-45) ports: 2
Serial ports quantity: 1
USB port: Yes
Battery
Hot-swap battery: Yes
Number of batteries supported: 1
Typical backup time at full load: 7 min
Typical backup time at half load: 21 min
Battery recharge time: 3 h
Battery technology: Sealed Lead Acid (VRLA)
Other features
Battery type: RBP0128
Logistics data
Harmonized System (HS) code: 8504408590
Warranty period: 3 year(s)
Safety warning
Warnings: Use the appliance in well-ventilated areas to avoid overheating., Do not disassemble the unit housing, there may be a risk of electric shock., Keep away from sources of fire and water.
Sustainability
Sustainability certificates: ENERGY STAR
Sustainability compliance: Yes
