Features Waveform: Pure sine Power protection features: Overload Output power capacity: 1.5 kVA Output power: 1350 W Automatic Voltage Regulation (AVR): Yes Output frequency: 50/60 Hz Audible alarm(s): Yes Power factor: 0.9 UPS topology: Line-Interactive Input operation voltage (max): 301 V Surge protection: Yes Input operation voltage (min): 151 V Output operation voltage (min): 230 V Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm Input frequency: 50/60 Hz Maximum current: 10 A Output operation voltage (max): 230 V Surge energy rating: 405 J EMI/RFI noise filtering: Yes Emergency Power Off (EPO): Yes Response time: 4 ms
Design Housing material: Metal Display type: LCD Form factor: Tower LED indicators: Operation, Error Product colour: Black
Operational conditions Non-operating altitude: 0 - 15000 m Storage temperature (T-T): -15 - 45 °C Storage relative humidity (H-H): 0 - 95% Operating relative humidity (H-H): 0 - 95% Operating temperature (T-T): 0 - 40 °C Operating altitude: 0 - 3000 m
Weight & dimensions Height: 221 mm Depth: 432 mm Width: 170 mm Weight: 25.1 kg
Packaging data Package height: 360 mm Package depth: 579 mm Package width: 316 mm Package weight: 27 kg
Packaging content Cables included: USB cable
Ports & interfaces Number of output IEC jumpers: 1 Power plug: C14 coupler Serial ports quantity: 1 USB port: Yes AC outlet types: C13 coupler AC outlets quantity: 8 AC outlet(s) USB 2.0 ports quantity: 1
Battery Typical backup time at full load: 5 min Number of batteries supported: 1 Typical backup time at half load: 17 min Battery technology: Sealed Lead Acid (VRLA) Battery recharge time: 8 h Hot-swap battery: Yes Compatible operating systems: Windows 7 / Vista / XP / 2000, Server 2003 / 2008, Linux
Other features Overload protection: Yes
Logistics data Harmonized System (HS) code: 8504408590 Country of origin: China
