Features Audible alarm(s): Yes Noise level: 52.5 dB Power protection features: Overload Output power: 1500 W Output operation voltage (max): 240 V Output power factor: 1 EMI/RFI noise filtering: Yes Output frequency: 50/60 Hz Surge protection: Yes Input operation voltage (min): 151 V Input operation voltage (max): 302 V Emergency Power Off (EPO): Yes Power Factor Correction (PFC) type: Active Output power capacity: 1500 kVA UPS topology: Line-Interactive Input frequency: 50/60 Hz Audible alarm modes: Low battery alarm, Fault, Overload alarm, Alarm when on battery Automatic Voltage Regulation (AVR): Yes Output operation voltage (min): 220 V Maximum current: 10 A Waveform: Pure sine Surge energy rating: 2430 J Certification: CE, FCC Class B, UL, RCM, VCCI Display: LCD Form factor: Rackmount/Tower
Design Housing material: Metal LED indicators: Yes Product colour: Black Rack capacity: 2U RoHS compliance: Y Cable length: 3.05 m
Operational conditions Storage relative humidity (H-H): 0 - 95% Operating temperature (T-T): 0 - 40 °C Operating altitude: 0 - 3000 m Operating relative humidity (H-H): 0 - 95% Storage temperature (T-T): -15 - 45 °C Non-operating altitude: 0 - 15000 m
Weight & dimensions Width: 433 mm Depth: 412 mm Height: 86.5 mm Weight: 29.4 kg
Packaging data Package height: 275 mm Package width: 560 mm Rack mount kit: Yes Power plug: C14 coupler
Ports & interfaces AC outlets quantity: 10 AC outlet(s) Ethernet LAN (RJ-45) ports: 2 USB 2.0 ports quantity: 1 USB port: Yes Serial ports quantity: 1 Serial interface type: RS-232 AC outlet types: C13 coupler Emergency Power Off (EPO) connector: Yes Serial interface: Yes
Battery Battery technology: Sealed Lead Acid (VRLA) Number of batteries supported: 1 Battery recharge time: 3 h Hot-swap battery: Yes
