Features Maximum current: 4.35 A Input operation voltage (min): 167 V Output frequency: 50/60 Hz Input operation voltage (max): 295 V EMI/RFI noise filtering: Yes Surge protection: Yes Waveform: Sine Output operation voltage (max): 230 V Surge energy rating: 450 J Automatic Voltage Regulation (AVR): Yes Input frequency: 50/60 Hz Output power capacity: 1 kVA Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm UPS topology: Line-Interactive Output power: 550 W Audible alarm(s): Yes Noise level: 40 dB Response time: 4 ms
Design Display type: LCD Housing material: Plastic Product colour: Black Cable length: 1.5 m LED indicators: Yes Form factor: Tower
Operational conditions Non-operating altitude: 0 - 3048 m Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 0 - 90% Storage temperature (T-T): -20 - 50 °C Storage relative humidity (H-H): 0 - 90% Operating altitude: 0 - 3048 m
Weight & dimensions Height: 227 mm Depth: 260 mm Weight: 6.23 kg Width: 100 mm
Ports & interfaces Serial interface: Yes USB port type: USB Type-B Serial interface type: RS-232 AC outlet types: Type E Ethernet LAN (RJ-45) ports: 1 AC outlets quantity: 4 AC outlet(s) Serial ports quantity: 1 USB port: Yes USB 2.0 ports quantity: 1
Battery Typical backup time at half load: 9 min Battery recharge time: 8 h Typical backup time at full load: 1 min Battery technology: Sealed Lead Acid (VRLA)
Safety warning Warnings: Keep away from sources of fire and water., Do not disassemble the unit housing, there may be a risk of electric shock., Use the appliance in well-ventilated areas to avoid overheating.
