Design
Product colour: Black
LED indicators: Speed, Activity, Power, Link
Rack mounting: Yes
Electromagnetic compatibility: CE A, VCCI A, FCC A, IC, BSMI
Power
AC input voltage: 100 - 240 V
Power consumption (max): 455.1 W
Power supply included: Yes
Security
Security algorithms: MD5, LEAP, SSH, SSL/TLS, PEAP, TTLS, EAP
IP-MAC-Port binding: Yes
Access Control List (ACL): Yes
Queue scheduling algorithms: Weighted Round Robin (WRR)
Loop protection: Yes
Access Control List (ACL) rules: 768
DHCP features: DHCP snooping, DHCP server
IGMP snooping: Yes
Operational conditions
Storage temperature (T-T): -20 - 70 °C
Operating temperature (T-T): -5 - 50 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Heat dissipation: 1551.891 BTU/h
Management features
Web-based management: Yes
System event log: Yes
ARP inspection: Yes
Quality of Service (QoS) support: Yes
Switch layer: L3
Configuring Location Settings (CLI): Yes
Switch type: Managed
Weight & dimensions
Weight: 3.46 kg
Depth: 250 mm
Width: 440 mm
Height: 44 mm
Network
Networking standards: IEEE 802.3af, IEEE 802.3at
Auto MDI/MDI-X: Yes
Link aggregation: Yes
Flow control support: Yes
Cable types supported: Cat5, Cat5e
Broadcast storm control: Yes
Spanning tree protocol: Yes
Head-of-line (HOL) blocking: Yes
Virtual LAN features: Voice VLAN
10G support: Yes
VLAN support: Yes
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 1000BASE-T
Number of VLANs: 4094
Port mirroring: Yes
Full duplex: Yes
Performance
Firmware upgradeable: Yes
Internal memory: 2048 MB
Noise level: 50.8 dB
Flash memory: 64 MB
Memory type: DDR3-SDRAM
Mean time between failures (MTBF): 463430.16 h
Packaging data
Package weight: 4.76 kg
Package width: 393 mm
Package depth: 563 mm
Package height: 89 mm
Ports & interfaces
Console port: RJ-45
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity: 4
Data transmission
Jumbo frames: 12000
Forwarding rate: 95.24 Mpps
Store-and-forward: Yes
Static route: Yes
Number of static routes: 124
MAC address table: 16000 entries
Packet buffer memory: 12 MB
Jumbo frames support: Yes
Switching capacity: 128 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 370 W
Power over Ethernet (PoE) ports quantity: 24
Power over Ethernet (PoE) power per port: 15.4 W
Multicast features
Multicast support: Yes
Optical fiber
Fiber ethernet cabling technology: 1000BASE-X, 1000BASE‑SX, 100BASE-FX, 1000BASE‑LX, 1000BASE‑ZX, 1000BASE-LHX
