Design
Rack mounting: Yes
Number of fans: 1 fan(s)
Product colour: Black
LED indicators: Yes
Stackable: Yes
Power
Power source: AC
Power consumption (max): 32 W
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Security
Access Control List (ACL) egress: 1000
Authentication type: RADIUS, TACACS+
Access Control List (ACL) ingress: 2000
MAC address filtering: Yes
Security algorithms: SNMP, SNMPv3, SNMPv2
IGMP snooping: Yes
Password protection: Yes
SSH/SSL support: Yes
Access Control List (ACL): Yes
Loop protection: Yes
Operational conditions
Storage relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -5 - 50 °C
Heat dissipation: 109.1 BTU/h
Management features
ARP inspection: Yes
Web-based management: Yes
Quality of Service (QoS) support: Yes
Traffic classification: Yes
Configuring Location Settings (CLI): Yes
Switch layer: L2
Switch type: Managed
Weight & dimensions
Height: 44 mm
Weight: 2.15 kg
Width: 440 mm
Depth: 140 mm
Network
Full duplex: Yes
Policy-based routing: Yes
Auto MDI/MDI-X: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x
Number of VLANs: 4096
10G support: Yes
Ethernet LAN data rates: 10,1000,100 Mbit/s
VLAN support: Yes
Port mirroring: Yes
Link aggregation: Yes
Auto-negotiation: Yes
Broadcast storm control: Yes
Spanning tree protocol: Yes
Flow control support: Yes
Performance
Noise level: 40.9 dB
Mean time between failures (MTBF): 530607 h
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 24
USB 2.0 ports quantity: 1
Console port: RJ-45
SFP+ module slots quantity: 4
USB Type-A ports quantity: 1
Data transmission
Packet buffer memory: 1.5 MB
MAC address table: 16000 entries
Jumbo frames support: Yes
Switching capacity: 128 Gbit/s
Forwarding rate: 95.24 Mpps
Store-and-forward: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
