Design
LED indicators: Power, Link, Speed, Activity
Electromagnetic compatibility: CE A, VCCI A, FCC A, IC, BSMI
Rack mounting: Yes
Product colour: Black
Power
AC input voltage: 100 - 240 V
Power supply included: Yes
Power consumption (max): 51.2 W
Security
Security algorithms: TTLS, SSL/TLS, SSH, LEAP, MD5, EAP, PEAP
DHCP features: DHCP server, DHCP client, DHCP snooping
IGMP snooping: Yes
IP-MAC-Port binding: Yes
Access Control List (ACL) rules: 768
Access Control List (ACL): Yes
Queue scheduling algorithms: Weighted Round Robin (WRR)
Loop protection: Yes
Operational conditions
Operating temperature (T-T): -5 - 50 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -20 - 70 °C
Heat dissipation: 174.592 BTU/h
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
System event log: Yes
Switch type: Managed
Switch layer: L3
ARP inspection: Yes
Configuring Location Settings (CLI): Yes
Weight & dimensions
Weight: 3.01 kg
Depth: 210 mm
Height: 44 mm
Width: 440 mm
Network
Networking standards: IEEE 802.3az, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1w
VLAN support: Yes
Number of VLANs: 4094
10G support: Yes
Auto MDI/MDI-X: Yes
Spanning tree protocol: Yes
Virtual LAN features: Voice VLAN
Link aggregation: Yes
Broadcast storm control: Yes
Flow control support: Yes
Head-of-line (HOL) blocking: Yes
Performance
Memory type: DDR3-SDRAM
Flash memory: 64 MB
Noise level: 50.7 dB
Mean time between failures (MTBF): 589984.72 h
Internal memory: 2048 MB
Packaging data
Package width: 351 mm
Package weight: 4.28 kg
Package depth: 565 mm
Package height: 91 mm
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 48
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity: 4
Console port: RJ-45
Data transmission
Jumbo frames support: Yes
Switching capacity: 176 Gbit/s
Packet buffer memory: 16 MB
MAC address table: 32000 entries
Number of static routes: 124
Jumbo frames: 12000
Static route: Yes
Forwarding rate: 130.95 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Optical fiber
Fiber ethernet cabling technology: 1000BASE-LHX, 1000BASE‑ZX, 1000BASE-X, 100BASE-FX, 1000BASE‑LX, 1000BASE‑SX
