Design
Stackable: Yes
LED indicators: Activity, Link, Power
Product colour: Black
Power
Power source: DC
Power supply included: Yes
DC input voltage: 12 V
Input current: 1 A
Power consumption (typical): 4.918 W
Security
IGMP snooping: Yes
Operational conditions
Storage relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -10 - 70 °C
Heat dissipation: 16.78 BTU/h
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Management features
Quality of Service (QoS) support: Yes
Switch type: Unmanaged
Switch layer: L2
Weight & dimensions
Weight: 238.6 g
Width: 100.5 mm
Depth: 82 mm
Height: 28 mm
Network
Networking standards: IEEE 802.3x, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p
Auto MDI/MDI-X: Yes
MAC address auto-learning supported: Yes
Flow control support: Yes
10G support: No
Performance
Mean time between failures (MTBF): 765190 h
Fanless: Yes
Certificates
Compliance certificates: RoHS, Low Voltage Directive (LVD), CE, BSMI
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
2.5G Ethernet (copper) ports quantity: 5
Data transmission
MAC address table: 4000 entries
Packet buffer memory: 8.1 MB
Store-and-forward: Yes
Forwarding rate: 18.6 Mpps
Switching capacity: 25 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Sustainability
Sustainability compliance: Yes
