Design
Product colour: Black
Rack mounting: No
Power
Power source: PoE
Power consumption (max): 24.08 W
Power supply included: No
Power consumption (typical): 3.24 W
Security
IGMP entries: 128
DHCP features: DHCP client
IGMP snooping: Yes
Static port security: Yes
SSH/SSL support: Yes
Queue scheduling algorithms: Weighted Round Robin (WRR)
MAC address entries: Static MAC address entries
Operational conditions
Storage relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 90%
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
Switch type: Managed
Weight & dimensions
Width: 150 mm
Depth: 97 mm
Weight: 380 g
Height: 28 mm
Network
Networking standards: IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3af, IEEE 802.3az, IEEE 802.3u
Ethernet LAN data rates: 10000 Mbit/s
VLAN support: Yes
Full duplex: Yes
Head-of-line (HOL) blocking: Yes
Virtual LAN features: Voice VLAN, Port-based VLAN, Management VLAN, Tagged VLAN
Auto-negotiation: Yes
Auto MDI/MDI-X: Yes
Port mirroring: Yes
10G support: No
Number of VLANs: 4094
Broadcast storm control: Yes
Flow control support: Yes
Half duplex: Yes
Performance
Flash memory: 2 MB
Noise level: 0 dB
Fanless: Yes
Mean time between failures (MTBF): 2357475 h
Certificates
Compliance certificates: BSMI, VCCI, Low Voltage Directive (LVD), Federal Communications Commission (FCC), CB
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 5
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
MAC address table: 2000 entries
Switching capacity: 10 Gbit/s
Forwarding rate: 7.44 Mpps
Number of trunks: 1
Jumbo frames: 9216
Packet buffer memory: 1 MB
Number of queues: 4
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 18 W
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) ports quantity: 2
