Design
Product colour: Black
Number of fans: 3 fan(s)
Rack mounting: Yes
Stackable: Yes
LED indicators: Yes
Power
Power source: AC
AC input frequency: 50/60 Hz
Power consumption (max): 482 W
AC input voltage: 100 - 240 V
Power supply included: Yes
Security
MAC address filtering: Yes
SSH/SSL support: Yes
Security algorithms: SNMPv2, SNMPv3, SNMP
Loop protection: Yes
IGMP snooping: Yes
Access Control List (ACL): Yes
Access Control List (ACL) ingress: 2000
Password protection: Yes
Access Control List (ACL) egress: 1000
Authentication type: RADIUS, TACACS+
Operational conditions
Storage temperature (T-T): -20 - 70 °C
Storage relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -5 - 50 °C
Operating relative humidity (H-H): 0 - 95%
Heat dissipation: 1643.62 BTU/h
Management features
Web-based management: Yes
Switch layer: L2
Quality of Service (QoS) support: Yes
Configuring Location Settings (CLI): Yes
ARP inspection: Yes
Traffic classification: Yes
Switch type: Managed
Weight & dimensions
Height: 44 mm
Weight: 4.35 kg
Width: 440 mm
Depth: 250 mm
Network
Full duplex: Yes
Spanning tree protocol: Yes
Number of VLANs: 4096
Auto-negotiation: Yes
Link aggregation: Yes
Auto MDI/MDI-X: Yes
Port mirroring: Yes
10G support: Yes
Broadcast storm control: Yes
Flow control support: Yes
Networking standards: IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3ae
Ethernet LAN data rates: 10,1000,100 Mbit/s
Policy-based routing: Yes
VLAN support: Yes
Performance
Mean time between failures (MTBF): 230300 h
Noise level: 52.7 dB
Ports & interfaces
Console port: RJ-45
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity: 4
USB 2.0 ports quantity: 1
Basic switching RJ-45 Ethernet ports quantity: 48
USB Type-A ports quantity: 1
Data transmission
Store-and-forward: Yes
MAC address table: 16000 entries
Packet buffer memory: 1.5 MB
Jumbo frames support: Yes
Switching capacity: 176 Gbit/s
Forwarding rate: 130.95 Mpps
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 48
Total Power over Ethernet (PoE) budget: 370 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
