Design
Rack mounting: Yes
Stackable: Yes
Product colour: Black
Number of fans: 2 fan(s)
LED indicators: Yes
Power
AC input frequency: 50/60 Hz
Power consumption (max): 44.1 W
Power source: AC
AC input voltage: 100 - 240 V
Security
IGMP snooping: Yes
Password protection: Yes
SSH/SSL support: Yes
Access Control List (ACL) egress: 1000
Authentication type: RADIUS, TACACS+
MAC address filtering: Yes
Access Control List (ACL) ingress: 2000
Security algorithms: SNMPv2, SNMPv3, SNMP
Access Control List (ACL): Yes
Loop protection: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -5 - 50 °C
Storage relative humidity (H-H): 0 - 95%
Heat dissipation: 150.38 BTU/h
Management features
ARP inspection: Yes
Configuring Location Settings (CLI): Yes
Traffic classification: Yes
Quality of Service (QoS) support: Yes
Switch layer: L2
Web-based management: Yes
Switch type: Managed
Weight & dimensions
Width: 440 mm
Height: 44 mm
Depth: 210 mm
Weight: 3.2 kg
Network
VLAN support: Yes
Policy-based routing: Yes
Full duplex: Yes
10G support: Yes
Flow control support: Yes
Ethernet LAN data rates: 10,1000,100 Mbit/s
Number of VLANs: 4096
Link aggregation: Yes
Spanning tree protocol: Yes
Broadcast storm control: Yes
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes
Networking standards: IEEE 802.3ae, IEEE 802.3x, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab
Port mirroring: Yes
Performance
Noise level: 54.7 dB
Mean time between failures (MTBF): 330520 h
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 48
USB Type-A ports quantity: 1
Console port: RJ-45
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
USB 2.0 ports quantity: 1
SFP+ module slots quantity: 4
Data transmission
Switching capacity: 176 Gbit/s
Forwarding rate: 130.95 Mpps
Store-and-forward: Yes
Jumbo frames support: Yes
Packet buffer memory: 1.5 MB
MAC address table: 16000 entries
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
