Technical details
Master (outer) cases per pallet (sea): 42 pc(s)
Products per pallet (air): 420 pc(s)
Pallet height (sea): 2.01 m
Pallet height (air): 2.01 m
Pallet gross weight (sea): 174 kg
Master (outer) cases per pallet (air): 42 pc(s)
Products per pallet (sea): 420 pc(s)
Pallet gross width: 110 cm
Shipping (inner) case height: 26.8 cm
Pallet gross weight (air): 174 kg
Pallet gross length: 120 cm
Shipping (inner) case net weight: 3.9 kg
Shipping (inner) case width: 38.3 cm
Shipping (inner) case length: 43.1 cm
Products per shipping (inner) case: 10 pc(s)
Shipping (inner) case gross weight: 4 kg
Features
6 GHz: No
5 GHz: Yes
Maximum data transfer rate: 1200 Mbit/s
Networking standards: IEEE 802.11ac, IEEE 802.11b, IEEE 802.3af, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n
Cabling technology: 10/100/1000Base-T(X)
Frequency band: 2.4, 5 GHz
Ethernet LAN data rates: 1000 Mbit/s, 100, 10
2.4 GHz: Yes
Transmitting power: 26 dBmW
Maximum data transfer rate (2.4 GHz): 300 Mbit/s
Mean time between failures (MTBF): 341897 h
Maximum data transfer rate (5 GHz): 867 Mbit/s
Design
Placement: Ceiling, Table, Wall
Product colour: White
Cable lock slot: Yes
LED indicators: Power
Power
DC voltage range: 12 V
Power consumption (max): 6.5 W
Power over Ethernet (PoE): Yes
Security
Security algorithms: 128-bit WEP, 64-bit WEP, SSID
Number of SSID supported: 16
Operational conditions
Storage temperature (T-T): -20 - 65 °C
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
Width: 170 mm
Height: 170 mm
Weight: 350 g
Depth: 28 mm
Packaging data
Package weight: 390 g
Package width: 208 mm
Package depth: 248 mm
Package height: 73 mm
Packaging content
Quantity per pack: 1 pc(s)
Ports & interfaces
WAN connection: Ethernet (RJ-45)
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
Antenna
Antenna type: Internal
Antenna features: Integrated antenna
Antennas quantity: 2
Antenna gain level (max): 3.8 dBi
Other features
Frequency range: 2400 - 5850 MHz
Logistics data
Harmonized System (HS) code: 85176990
