Features
Mean time between failures (MTBF): 3960000 h
Product colour: Gold, Metallic
Hot-Plug support: Yes
Power
Maximum current: 300 A
Maximum voltage: 3.3 V
Operational conditions
Storage temperature (T-T): -40 - 85 °C
Operating temperature (T-T): 0 - 70 °C
Operating relative humidity (H-H): 5 - 85%
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Width: 14.8 mm
Depth: 11.8 mm
Weight: 18 g
Height: 56.5 mm
Performance
Fiber ethernet cabling technology: 10GBASE
SFP transceiver standard: SR
Wavelength: 850 nm
Single-mode fiber (SMF) supported: No
Tx power (min): -6.5 dBmW
SFP transceiver type: Fiber optic
Interface type: SFP+
Fiber optic connector: LC
Networking standards: IEEE 802.3ae
Fiber cable diameters supported (core/cladding): 62.5/125 µm, 50/125
Maximum transfer distance: 550 m
Maximum data transfer rate: 10000 Mbit/s
Tx power (max): -1 dBmW
Multi-mode fiber (MMF) supported: Yes
Rx power (max): -1 dBmW
Rx power (min): -11.1 dBmW
Link budget: 10.1 dB
Duplex system: Full
Packaging data
Package depth: 131 mm
Package height: 49 mm
Package weight: 64 g
Package width: 74 mm
Certification: CE, FCC, VCCI, C-Tick, MSA
Certificates
Safety: UL, TUV, CDRH
Compliance certificates: RoHS
Logistics data
Products per shipping (inner) case: 50 pc(s)
Harmonized System (HS) code: 85369010
Shipping (inner) case length: 36 cm
Shipping (inner) case height: 31 cm
Pallet gross length: 102 cm
Pallet gross width: 122 cm
Shipping (inner) case gross weight: 4.2 kg
Shipping (inner) case width: 26 cm
Master (outer) cases per pallet (sea): 60 pc(s)
Products per pallet (sea): 3000 pc(s)
Pallet gross weight (sea): 272 kg
Products per pallet (air): 3000 pc(s)
Master (outer) cases per pallet (air): 60 pc(s)
Pallet height (sea): 199 cm
Pallet height (air): 199 cm
Pallet gross weight (air): 272 kg
Shipping (inner) case net weight: 3.2 kg
