Design
Product colour: Black
LED indicators: Link, Power, Status, Activity, PoE, Speed
Housing material: Metal
Rack mounting: No
Wall mountable: Yes
Power
Power supply included: Yes
Security
Packet filtering: 7.44 Mpps
Operational conditions
Storage temperature (T-T): -10 - 70 °C
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Management features
Quality of Service (QoS) support: Yes
Switch type: Unmanaged
Weight & dimensions
Height: 28 mm
Weight: 260 g
Depth: 98 mm
Width: 100 mm
Network
Copper ethernet cabling technology: 1000BASE-T, 100BASE-TX, 10BASE-T
Auto MDI/MDI-X: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3az, IEEE 802.3at, IEEE 802.3u
Auto-negotiation: Yes
Full duplex: Yes
MAC address auto-learning supported: Yes
10G support: No
Performance
Buffer size: 64 KB
Plug and Play: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 5
Power connector: DC-in jack
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 5
Data transmission
MAC address table: 2000 entries
Forwarding rate: 7.44 Mpps
Switching capacity: 10 Gbit/s
Store-and-forward: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 4
Total Power over Ethernet (PoE) budget: 60 W
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet (PoE): Yes
