Design
Electromagnetic compatibility: FCC Class A, CE Class A, VCCI Class A, C-Tick, BSMI
Rack mounting: Yes
Number of fans: 1 fan(s)
Form factor: 1U
Product colour: Black
Power
Power supply included: Yes
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power source: DC/PoE
Security
IGMP snooping: Yes
Operational conditions
Heat dissipation: 125.2 BTU/h
Operating temperature (T-T): -5 - 50 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -40 - 70 °C
Management features
Switch type: Managed
Switch layer: L2
Quality of Service (QoS) support: Yes
Weight & dimensions
Width: 280 mm
Depth: 230 mm
Height: 44 mm
Weight: 2.1 kg
Network
Auto-negotiation: Yes
Link aggregation: Yes
Full duplex: Yes
Spanning tree protocol: Yes
10G support: No
Number of VLANs: 4094
Copper ethernet cabling technology: 1000BASE-T
Half duplex: Yes
Networking standards: IEEE 802.3bt, IEEE 802.3at, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3az
Flow control support: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Auto MDI/MDI-X: Yes
VLAN support: Yes
Performance
Mean time between failures (MTBF): 343695 h
Noise level: 45.8 dB
Certification: cUL, UL, LVD, CB, BSMI
Certificates
Compliance certificates: RoHS
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity: 2
Basic switching RJ-45 Ethernet ports quantity: 16
Data transmission
Jumbo frames: 9216
Forwarding rate: 26.78 Mpps
Jumbo frames support: Yes
Switching capacity: 36 Gbit/s
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 130 W
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) ports quantity: 16
