Design
Product colour: Black, Grey
LED indicators: Yes
Power
Power supply included: Yes
Power source: AC
AC input frequency: 50/60 Hz
Power consumption (max): 9.4 W
Number of power supply units: 1
AC input voltage: 100 - 240 V
Security
IGMP snooping: Yes
Loop protection: Yes
Operational conditions
Storage relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -5 - 50 °C
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -40 - 70 °C
Heat dissipation: 507.23 BTU/h
Management features
Web-based management: Yes
Switch layer: L2
Quality of Service (QoS) support: Yes
Switch type: Managed
Weight & dimensions
Height: 44 mm
Width: 330 mm
Depth: 180 mm
Weight: 1.77 kg
Network
Networking standards: IEEE 802.3at, IEEE 802.3x, IEEE 802.3u, IEEE 802.3z, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az
Flow control support: Yes
Link aggregation: Yes
VLAN support: Yes
Port mirroring: Yes
Auto MDI/MDI-X: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Spanning tree protocol: Yes
Full duplex: Yes
Broadcast storm control: Yes
Head-of-line (HOL) blocking: Yes
Number of VLANs: 256
10G support: No
Half duplex: Yes
Performance
Flash memory: 32 MB
Internal memory: 128 MB
Mean time between failures (MTBF): 1274005 h
Certificates
Compliance certificates: CCC, BSMI, CB, cUL
Ports & interfaces
Installed SFP modules quantity: 2
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Data transmission
Static route: Yes
MAC address table: 8000 entries
Packet buffer memory: 4.1 MB
Forwarding rate: 14.88 Mpps
Switching capacity: 20 Gbit/s
Number of static routes: 256
Jumbo frames: 10000
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 8
Total Power over Ethernet (PoE) budget: 130 W
Power over Ethernet (PoE): Yes
Sustainability
Sustainability compliance: Yes
