Design
Form factor: 1U
Number of fans: 2 fan(s)
Rack mounting: Yes
Product colour: Grey, Black
LED indicators: Link, Speed, Activity, Power, Fan fail
Electromagnetic compatibility: FCC A, CE A, VCCI, C-Tick, BSMI, CCC
Power
AC input frequency: 50 - 60 Hz
Power source: AC/DC
AC input voltage: 100 - 240 V
Power consumption (typical): 27.49 W
Security
Security algorithms: SNMP, SSH, 802.1x RADIUS
BPDU filtering/protection: Yes
IGMP snooping: Yes
IP-MAC-Port binding: Yes
Authentication: Guest VLAN, MAC-based authentication, Port-based authentication
SSH/SSL support: Yes
DHCP features: DHCP client
Access Control List (ACL) rules: 256
Access Control List (ACL): Yes
Loop protection: Yes
Operational conditions
Operating temperature (T-T): -5 - 50 °C
Storage relative humidity (H-H): 5 - 90%
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 70 °C
Heat dissipation: 850.58 BTU/h
Management features
Quality of Service (QoS) support: Yes
Web-based management: Yes
Switch layer: L2
Traffic classification: Yes
Switch type: Managed
Weight & dimensions
Depth: 210 mm
Weight: 3.86 kg
Height: 44 mm
Width: 440 mm
Network
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1x, IEEE 802.3u, IEEE 802.1D, IEEE 802.3z, IEEE 802.1w, IEEE 802.3az, IEEE 802.1v, IEEE 802.3ah
Auto MDI/MDI-X: Yes
VLAN support: Yes
Copper ethernet cabling technology: 1000BASE-T, 100BASE-TX, 10BASE-T, 100BASE-T
Full duplex: Yes
10G support: No
Virtual LAN features: Voice VLAN, MAC address-based VLAN, Tagged VLAN, Port-based VLAN
Rate limiting: Yes
Auto-negotiation: Yes
Number of VLANs: 4094
Link aggregation: Yes
Spanning tree protocol: Yes
Port mirroring: Yes
Flow control support: Yes
IP routing: Yes
Performance
Flash memory: 32 MB
Noise level: 52.4 dB
Memory type: DDR3-SDRAM
Internal memory: 256 MB
Ports & interfaces
SFP module slots quantity: 4
Fiber optic connector: SFP
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 24
Console port: RJ-45
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Switching capacity: 56 Gbit/s
Jumbo frames support: Yes
Packet buffer memory: 1.5 MB
Number of static routes: 32
Store-and-forward: Yes
Jumbo frames: 9216
MAC address table: 16000 entries
Number of queues: 8
Forwarding rate: 41.7 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 24
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
Multicast Listener Discovery (MLD) snooping: MLD v1, MLD v2
Optical fiber
Fiber ethernet cabling technology: 1000BASE-X
