Design
Product colour: Black, Grey
LED indicators: Yes
Power
Number of power supply units: 1
AC input frequency: 50/60 Hz
Power supply included: Yes
Power consumption (max): 54.4 W
Power source: AC
AC input voltage: 100 - 240 V
Security
Loop protection: Yes
IGMP snooping: Yes
Operational conditions
Heat dissipation: 507.23 BTU/h
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): -5 - 50 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Management features
Switch type: Managed
Switch layer: L2
Quality of Service (QoS) support: Yes
Web-based management: Yes
Weight & dimensions
Width: 440 mm
Height: 44 mm
Weight: 6.26 kg
Depth: 430 mm
Network
Port mirroring: Yes
Flow control support: Yes
Number of VLANs: 256
Full duplex: Yes
Half duplex: Yes
10G support: No
Spanning tree protocol: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Head-of-line (HOL) blocking: Yes
Auto MDI/MDI-X: Yes
Networking standards: IEEE 802.3af, IEEE 802.3az, IEEE 802.3x, IEEE 802.3at, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.3z
VLAN support: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Performance
Internal memory: 128 MB
Flash memory: 32 MB
Mean time between failures (MTBF): 236406 h
Certificates
Compliance certificates: CCC, BSMI, CB, cUL
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity: 4
Basic switching RJ-45 Ethernet ports quantity: 48
Data transmission
Number of static routes: 256
Static route: Yes
MAC address table: 16000 entries
Packet buffer memory: 12 MB
Forwarding rate: 77.4 Mpps
Jumbo frames: 10000
Jumbo frames support: Yes
Switching capacity: 104 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 370 W
Power over Ethernet (PoE) ports quantity: 48
Sustainability
Sustainability compliance: Yes
