Technical details
Pallet gross length: 110 cm
Shipping (inner) case height: 48.5 cm
Products per shipping (inner) case: 3 pc(s)
Master (outer) cases per pallet (sea): 24 pc(s)
Products per pallet (air): 72 pc(s)
Pallet gross width: 120 cm
Pallet gross weight (air): 561.6 kg
Shipping (inner) case length: 53 cm
Shipping (inner) case net weight: 14.3 kg
Pallet gross weight (sea): 561.6 kg
Shipping (inner) case gross weight: 22.6 kg
Products per pallet (sea): 72 pc(s)
Master (outer) cases per pallet (air): 24 pc(s)
Shipping (inner) case width: 38.5 cm
Pallet height (air): 2.08 m
Pallet height (sea): 2.08 m
Design
Safety: cUL, CB
Stackable: Yes
Rack mounting: Yes
Number of fans: 2 fan(s)
LED indicators: Power, Speed, Activity, Link, PoE
Product colour: Black, Grey
Power
Power consumption (max): 436.3 W
Power supply included: Yes
Power source: AC
AC input voltage: 100 - 240 V
Security
BPDU filtering/protection: Yes
Access Control List (ACL) rules: 768
DHCP features: DHCP client, DHCP server
IGMP snooping: Yes
SSH/SSL support: Yes
Authentication: MAC-based authentication, Port-based authentication
Access Control List (ACL): Yes
Security algorithms: SSH, SNMP, SSH-2, 802.1x RADIUS, SSL/TLS, EAP
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Heat dissipation: 1487.78 BTU/h
Storage relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -5 - 50 °C
Storage temperature (T-T): -20 - 70 °C
Management features
Quality of Service (QoS) support: Yes
Traffic classification: Yes
Switch layer: L2/L3
System event log: Yes
Switch type: Managed
Weight & dimensions
Height: 44 mm
Width: 440 mm
Depth: 308.5 mm
Weight: 4.25 kg
Network
Copper ethernet cabling technology: 1000BASE-T, 10BASE-T, 100BASE-TX
Flow control support: Yes
10G support: Yes
Number of VLANs: 4094
VLAN support: Yes
Full duplex: Yes
Auto-negotiation: Yes
Port mirroring: Yes
Auto MDI/MDI-X: Yes
Virtual LAN features: Tagged VLAN, Protocol-based VLAN
MAC address auto-learning supported: Yes
Head-of-line (HOL) blocking: Yes
Cable types supported: Cat5, Cat5e
Broadcast storm control: Yes
Spanning tree protocol: Yes
Link aggregation: Yes
Networking standards: IEEE 802.3at, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1w, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.1x, IEEE 802.1D, IEEE 802.3ae
Performance
Internal memory: 256 MB
Flash memory: 32 MB
Mean time between failures (MTBF): 274796 h
Built-in processor: Yes
Processor frequency: 400 MHz
Packaging data
Package depth: 510 mm
Package height: 121 mm
Package width: 450 mm
Package weight: 7.06 kg
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Fiber optic connector: SFP+
SFP+ module slots quantity: 4
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Switching capacity: 128 Gbit/s
Packet buffer memory: 1.5 MB
MAC address table: 16384 entries
Number of queues: 8
Throughput: 95.24 Mpps
Jumbo frames: 9216
Store-and-forward: Yes
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 24
Total Power over Ethernet (PoE) budget: 370 W
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
