Technical details
Pallet gross weight (air): 375.1 kg
Pallet gross weight (sea): 375.1 kg
Shipping (inner) case height: 39.8 cm
Shipping (inner) case gross weight: 14.9 kg
Products per pallet (sea): 72 pc(s)
Master (outer) cases per pallet (air): 24 pc(s)
Products per pallet (air): 72 pc(s)
Master (outer) cases per pallet (sea): 24 pc(s)
Products per shipping (inner) case: 3 pc(s)
Pallet height (air): 173 cm
Shipping (inner) case net weight: 11.4 kg
Pallet height (sea): 173 cm
Pallet gross length: 110 cm
Pallet gross width: 120 cm
Shipping (inner) case length: 57.3 cm
Shipping (inner) case width: 32.4 cm
Design
Stackable: Yes
LED indicators: Link, Activity, Power
Number of fans: 2 fan(s)
Form factor: 1U
Safety: cUL, CB
Rack mounting: Yes
Product colour: Black
Power
AC input voltage: 100 - 240 V
Power consumption (max): 44.2 W
AC input frequency: 50 - 60 Hz
Security
Access Control List (ACL): Yes
SSH/SSL support: Yes
DHCP features: DHCP client, DHCP server
MAC address filtering: Yes
IGMP snooping: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Heat dissipation: 138.8 BTU/h
Operating temperature (T-T): -5 - 50 °C
Storage relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -20 - 70 °C
Management features
Switch type: Managed
Cloud-managed: No
Switch layer: L3
Web-based management: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Weight: 5.3 kg
Depth: 250 mm
Width: 440 mm
Height: 44 mm
Network
Port mirroring: Yes
Flow control support: Yes
Broadcast storm control: Yes
Link aggregation: Yes
Head-of-line (HOL) blocking: Yes
Full duplex: Yes
Auto MDI/MDI-X: Yes
VLAN support: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3u, IEEE 802.3ae
10G support: Yes
Performance
Noise level: 45.8 dB
Packaging data
Package height: 101 mm
Package width: 365 mm
Package weight: 4.62 kg
Package depth: 555 mm
Ports & interfaces
SFP+ module slots quantity: 4
Basic switching RJ-45 Ethernet ports quantity: 48
Power connector: DC-in jack
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Store-and-forward: Yes
Throughput: 130.95 Mpps
MAC address table: 16000 entries
Packet buffer memory: 3 MB
Switching capacity: 176 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
