Technical details
Pallet gross length: 110 cm
Pallet gross width: 120 cm
Shipping (inner) case gross weight: 12.7 kg
Pallet gross weight (air): 247.3 kg
Pallet gross weight (sea): 399.6 kg
Master (outer) cases per pallet (sea): 30 pc(s)
Shipping (inner) case length: 56.2 cm
Shipping (inner) case width: 31.4 cm
Products per pallet (sea): 90 pc(s)
Shipping (inner) case net weight: 11.7 kg
Pallet height (sea): 2.05 m
Pallet height (air): 128.4 cm
Shipping (inner) case height: 38.3 cm
Products per shipping (inner) case: 3 pc(s)
Master (outer) cases per pallet (air): 18 pc(s)
Products per pallet (air): 54 pc(s)
Design
LED indicators: Yes
Safety: cUL, CB, CE, CCC, BSMI
Product colour: Silver, Black
Rack mounting: Yes
Form factor: 1U
Power
Power consumption (typical): 43.81 W
AC input voltage: 100 - 240 V
Security
IGMP snooping: Yes
Operational conditions
Operating temperature (T-T): -5 - 50 °C
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -40 - 70 °C
Management features
Quality of Service (QoS) support: Yes
MIB support: Y
Switch type: Managed
Switch layer: L2
Weight & dimensions
Height: 44 mm
Depth: 440 mm
Width: 210 mm
Weight: 2.73 kg
Network
Networking standards: IEEE 802.3z, IEEE 802.3ae, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3an, IEEE 802.3az
VLAN support: Yes
Auto MDI/MDI-X: Yes
Cable types supported: Cat6, Cat6a, Cat7
Spanning tree protocol: Yes
10G support: Yes
Packaging data
Package weight: 3.91 kg
Package height: 96 mm
Package depth: 546 mm
Package width: 349 mm
Ports & interfaces
Fiber optic connector: SFP+
Basic switching RJ-45 Ethernet ports quantity: 2
Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
SFP+ module slots quantity: 10
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Jumbo frames support: Yes
Switching capacity: 240 Gbit/s
MAC address table: 16000 entries
Throughput: 178.56 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Sustainability
Sustainability certificates: ENERGY STAR
