Technical details
Pallet gross weight (sea): 451.2 kg
Master (outer) cases per pallet (sea): 30 pc(s)
Pallet height (air): 128.4 cm
Products per pallet (sea): 90 pc(s)
Pallet height (sea): 2.05 m
Shipping (inner) case length: 56.2 cm
Pallet gross length: 110 cm
Shipping (inner) case gross weight: 14.4 kg
Shipping (inner) case height: 38.3 cm
Pallet gross width: 120 cm
Products per shipping (inner) case: 3 pc(s)
Shipping (inner) case width: 31.4 cm
Master (outer) cases per pallet (air): 18 pc(s)
Products per pallet (air): 54 pc(s)
Pallet gross weight (air): 278.2 kg
Shipping (inner) case net weight: 13.4 kg
Design
Form factor: 1U
Product colour: Black, Silver
Rack mounting: Yes
LED indicators: Yes
Safety: cUL, CB, CE, CCC, BSMI
Power
AC input voltage: 100 - 240 V
Power consumption (typical): 90.81 W
Security
IGMP snooping: Yes
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): -5 - 50 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Quality of Service (QoS) support: Yes
Switch layer: L2
Switch type: Managed
Weight & dimensions
Width: 210 mm
Height: 44 mm
Weight: 3.15 kg
Depth: 440 mm
Network
10G support: Yes
Networking standards: IEEE 802.3u, IEEE 802.3ab, IEEE 802.3an, IEEE 802.3az, IEEE 802.3z, IEEE 802.3ae
VLAN support: Yes
Auto MDI/MDI-X: Yes
Spanning tree protocol: Yes
Packaging data
Package depth: 546 mm
Package width: 349 mm
Package weight: 4.48 kg
Package height: 96 mm
Ports & interfaces
Power connector: DC-in jack
Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity: 10
Fiber optic connector: SFP+
SFP+ module slots quantity: 2
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Switching capacity: 240 Gbit/s
MAC address table: 16000 entries
Jumbo frames support: Yes
Throughput: 178.56 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Sustainability
Sustainability certificates: ENERGY STAR
