Design
Mounting type: Ceiling
Housing material: Metal, Plastic
Product colour: White
Form factor: Dome
International Protection (IP) code: IP67
Power
DC output voltage: 12
Power consumption (max): 4.4 W
Power consumption (typical): 2.1 W
Power source type: DC, PoE
Security
Human and vehicle targets classification: Yes
Mirror: Yes
IP address filtering: Yes
Video motion detection: Yes
Operational conditions
Storage temperature (T-T): -40 - 60 °C
Operating temperature (T-T): -40 - 60 °C
Weight & dimensions
Height: 99.1 mm
Diameter: 12.2 cm
Weight: 460 g
Network
Ethernet interface type: Fast Ethernet
Supported network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, NTP, ICMP, IGMP, P2P
Streaming method: Multicast
Ethernet LAN: Yes
Wi-Fi: No
Networking standards: IEEE 802.3af, IEEE 802.1x
Bluetooth: No
System requirements
Mobile operating systems supported: iOS, Android
Performance
Day/night mode: Yes
Wide Dynamic Range (WDR): Yes
Placement supported: Outdoor
Dynamic range: 120 dB
Connectivity technology: Wired
Type: IP security camera
Packaging data
Package weight: 650 g
Packaging content
Number of cameras: 1
Manual: Yes
Audio
Audio formats supported: G.711, G.711 μ-law, G.726, PCM
Built-in microphone: Yes
Storage
Maximum memory card size: 256 GB
RAM capacity: 128 MB
Built-in HDD: No
ROM capacity: 128 MB
Compatible memory cards: MicroSD (TransFlash)
Card reader integrated: Yes
Ports & interfaces
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
Camera
Number of Privacy masking areas: 4
Lens viewing angle, horizontal: 95°
Lens viewing angle, vertical: 52°
Lens viewing angle, diagonal: 114°
Pan range: 0 - 360°
Minimum illumination: 0.0006 lx
Camera tilt control: Yes
Camera shutter speed: 1/3 - 1/100000 s
White balance: Natural, Regional custom, Street lamp, Manual, Auto, Outdoor
Camera pan control: Yes
Angle of rotation: 360°
Tilt angle range: 0 - 78°
Image sensor
Optical sensor size: 25.4 / 2.9 mm (1 / 2.9")
Progressive scan: Yes
Number of sensors: 1
Sensor type: CMOS
Video
Total megapixels: 4 MP
Video recording: Yes
Region of Interest (ROI) encoding: Yes
Gain control type: Auto/Manual
Noise reduction technology: 3D noise reduction
Video compression formats: M-JPEG, H.264, H.264H, H.264B, H.265
Frame rate: 30 fps
Video streaming: Yes
Noise reduction: Yes
Back Light Compensation (BLC): Yes
Highlight Compensation (HLC): Yes
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Maximum resolution: 2688 x 1520 pixels
Night vision
Colour night vision distance: 30 m
Night vision: Yes
Night vision distance: 30 m
Number of illumination LEDs: 2
LED type: IR
Lens system
Observe distance: 25.4 m
Maximum aperture number: 1.6
Recognize distance: 12.7 m
Fixed focus: Yes
Detect distance: 63.6 m
Fixed focal length: 2.8 mm
Identify distance: 6.4 m
Closest focusing distance: 0.9 m
Safety warning
Warnings: The product contains electronic components; do not dispose of with the normal household waste., Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling.
Sustainability
Compliance certificates: UL, CE, Federal Communications Commission (FCC)
