Design
Mounting type: Wall/ceiling
Product colour: White
International Protection (IP) code: IP67
Form factor: Tube/dome
Housing material: Metal, Plastic
Power
Power source type: DC
DC output voltage: 12
Power consumption (typical): 2 W
Power consumption (max): 4.1 W
Operational conditions
Storage temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -30 - 70 °C
Management features
Web-based management: Yes
Web browser: Yes
Weight & dimensions
Weight: 477.9 g
Height: 128.6 mm
Width: 70 mm
Depth: 166.2 mm
Network
Networking standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum range: 80 m
Ethernet interface type: 10 Megabit Ethernet, 100 Megabit Ethernet
4G LTE: No
Bluetooth: No
Wi-Fi: Yes
Wi-Fi band: Single-band (2.4 GHz)
System requirements
Mobile operating systems supported: Android, iOS
Performance
Type: IP security camera
Placement supported: Outdoor
Connectivity technology: Wired & Wireless
Wide Dynamic Range (WDR): DWDR
Signal-to-Noise Ratio (SNR): 56 dB
Packaging content
Number of cameras: 1
Audio
Built-in microphone: Yes
Built-in loudspeaker: No
Two-way talk: N
Storage
RAM capacity: 64 MB
ROM capacity: 16 MB
Ports & interfaces
Number of memory card slots: 1
Compatible memory cards: MicroSDHC, MicroSD (TransFlash), MicroSDXC
Alarm input/output: No
Maximum memory card size: 256 GB
Camera
Lens viewing angle, horizontal: 100°
Vertical rotation angle: 0 - 90°
People detection : Yes
Viewing angle, diagonal: 120°
Horizontal rotation angle: 0 - 360°
Motion detection : Yes
Lens viewing angle, vertical: 53°
Camera shutter speed: 1/3 - 1/100000 s
Minimum illumination: 0.025 lx
Adjustment shutter speed: Auto/Manual
Image sensor
Number of sensors: 1
Sensor type: HD CMOS
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Progressive scan: Yes
Video
Video compression formats: H.265, H.264+, H.264B, H.264, M-JPEG, H.264H, H.265+
Video streaming: Yes
Maximum resolution: 1920 x 1080 pixels
Total megapixels: 2 MP
Frame rate: 25 / 30 fps
Night vision
Night vision: Yes
Number of illumination LEDs: 1
Night vision distance: 30 m
LED type: IR
Lens system
Closest focusing distance: 0.6 m
Aperture type: Permanent
Lens type: Fixed focal length lens
Maximum aperture number: 2
Number of lenses: 1
Focal length range: 2.8 mm
Safety warning
Warnings: The product contains electronic components; do not dispose of with the normal household waste., Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling.
