Design
Form factor: Bullet
Product colour: White
International Protection (IP) code: IP67
Mounting type: Ceiling/wall
Housing material: Metal, Plastic
Power
Power consumption (max): 7.9 W
Power source type: DC, PoE
Power consumption (Power over Ethernet (PoE)): 9.8 W
DC output voltage: 12
Security
Video motion detection: Yes
Mirror: Yes
Intelligent Video Surveillance (IVS) system features: Intrusion, Tripwire
Operational conditions
Operating temperature (T-T): -30 - 60 °C
Storage temperature (T-T): -40 - 60 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Management features
Web browser: Yes
Weight & dimensions
Length: 288.4 mm
Weight: 1.05 kg
Width: 94.4 mm
Height: 84.7 mm
Network
Bluetooth: No
Quality of Service (QoS) support: Yes
Networking standards: IEEE 802.3af, IEEE 802.1x
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: Fast Ethernet
Number of users: 20 user(s)
Streaming method: Multicast
System requirements
Mobile operating systems supported: iOS, Android
Certification: CE-LVD: EN 62368-1; CE-EMC: 2014/30/EU; FCC: 47 CFR FCC B; UL/CUL:UL62368-1; CAN/CSA C22.2; 62368-1-14
Performance
Connectivity technology: Wired
Type: IP security camera
Wide Dynamic Range (WDR): Yes
Alarm input/output: Yes
Placement supported: Outdoor
Day/night mode: Yes
Packaging data
Package weight: 1.35 kg
Packaging content
Number of cameras: 1
Audio
Audio output channels: 1.0 channels
Audio input channels: 1.0 channels
Storage
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash)
Internal memory: 1000 MB
ROM capacity: 128 MB
Built-in HDD: No
Maximum memory card size: 256 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Tilt angle range: 0 - 90°
Lens viewing angle, horizontal: 108°
Lens viewing angle, diagonal: 130°
Lens viewing angle, vertical: 56°
White balance: Outdoor, Auto, Natural, Street lamp, Manual
Angle of rotation: 360°
Minimum illumination: 0.004 lx
Camera tilt control: Yes
Camera shutter type: Electronic
Pan range: 0 - 360°
Camera shutter speed: 1/3 – 1/100,000
Adjustment shutter speed: Auto/Manual
Camera pan control: Yes
Image sensor
Sensor type: CMOS
Number of sensors: 1
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Progressive scan: Yes
Video
Supported graphics resolutions: 640 x 480 (VGA), 3072 x 2048, 3840 x 2160, 2592 x 1944, 1920 x 1080 (HD 1080), 3072 x 1728, 1280 x 720 (HD 720), 704 x 480, 2688 x 1520, 352 x 288, 352 x 240, 704 x 576, 1280 x 960
Maximum resolution: 3840 x 2160 pixels
Video compression formats: H.265, H.264B, H.264+, H.264, H.265+, M-JPEG
Noise reduction technology: 3D noise reduction
Frame rate: 30 fps
Back Light Compensation (BLC): Yes
Highlight Compensation (HLC): Yes
Privacy masking: Yes
Total megapixels: 8 MP
Video streaming: Yes
Noise reduction: Yes
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Bit rate: 3 kbps–8192
Region of Interest (ROI) encoding: Yes
Night vision
Night vision: Yes
LED type: IR
Night vision distance: 50 m
Number of illumination LEDs: 2
Lens system
Maximum aperture number: 1.2
Observe distance (wide): 36 m
Detect distance (wide): 89.9 m
Number of lenses: 1
Detect distance (tele): 257.4 m
Focal length range: 2.7 mm
Recognize distance (tele): 51.5 m
Closest focusing distance: 1.5 m
Identify distance (wide): 19 m
Identify distance (tele): 25.7 m
Observe distance (tele): 103 m
Recognize distance (wide): 18 m
Safety warning
Warnings: The product contains electronic components; do not dispose of with the normal household waste., Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling.
