Certification: CE EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014CE-LVD: EN 62368-1:2014EN 55032:2015, Class A, EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55024:2010+A1:2015;EN 55035:2017, EN 50130-4:2011+A1:2014, CE LVD: EN 62368-1:2014, FCC: 47 CFR FCC Part15, SubpartB, Class A 2023-02-15
Features
Product colour: Black
Power
Current: 1.2 A
Power consumption (typical): 53 W
Power source type: DC, PoE
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Storage relative humidity (H-H): 10 - 93%
Weight & dimensions
Height: 47.6 mm
Width: 260 mm
Depth: 232.7 mm
Weight: 860 g
Supported resolutions: 4608x3472, 3840x2160, 1920x1080, 1280x1024, 1280x720, 1920x1080, 1280x1024, 1280x720
Performance
Recording modes: Motion detection, manual recording, smart recording, alarm
Backup function: Yes
Audio codecs: G.711a, G.711Mu, G.726, PCM
Total megapixels: 16 MP
Video motion detection: Yes
Video input channels: 4 channels
Video formats supported: H.264+, H.265+, H.265, H.264
Playback modes: Instant playback, general playback, event playback, smart playback
Maximum resolution: 4608 x 3472 pixels
People counting function: No
Storage
Maximum storage capacity: 16 TB
HDD interface: SATA III
Ports & interfaces
Power over Ethernet (PoE): No
USB 2.0 ports quantity: 2
Audio RCA outputs: 1
Ethernet LAN data rates: 10,100 Mbit/s
HDMI ports quantity: 1
VGA (D-Sub) output ports: 1
Power over Ethernet (PoE) ports quantity: 4
Number of SATA connectors: 1
RCA input: 1
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Networking standards: IEEE 802.3 af/at
Power over Ethernet (PoE) ports quantity: 4
