Processor
Built-in processor: Yes
Features
Rack capacity: 1U
Product colour: Black
Power
Current: 2 A
Power management: DC 12 V
Operational conditions
Storage relative humidity (H-H): 10 - 93%
Operating temperature (T-T): -10 - 55 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Width: 260 mm
Weight: 810 g
Depth: 232.5 mm
Height: 47.6 mm
Network
Ethernet LAN data rates: 10,100,1000 Mbit/s
Client interoperability: ONVIF (Profile S / (Profile T / (Profile G), CGI, SDK
System requirements
Mobile operating systems supported: iOS, Android
Performance
Video formats supported: H.265+, H.264, H.264+, H.265
Backup function: Yes
Playback modes: Instant playback, general playback, event playback, tag playback, smart playback
Multi-screen: Yes
Video input channels: 16 channels
Audio codecs: G.711a; G.711u; PCM; G726
Operating system installed: Embedded LINUX
Maximum resolution: 3840 x 2160 pixels
Number of simultaneously playbacked channels: 16 channels
Video motion detection: Yes
People counting: Yes
Ports & interfaces
USB 2.0 ports quantity: 2
HDMI ports quantity: 1
HDMI output: Yes
Audio RCA outputs: 1
Ethernet LAN (RJ-45) ports: 1
VGA (D-Sub) output ports: 1
RCA input: 1
Hard drive
Number of SATA connectors: 1
Number of HDDs supported: 1
Maximum storage capacity: 20 TB
Safety warning
Warnings: Do not expose the device to moisture or extreme temperatures., The appliance should be installed by a qualified professional., The product must be disposed of in accordance with local hazardous waste regulations.
