Processor
Built-in processor: Yes
Features
Product colour: White
Power
AC input frequency: 47 - 63 Hz
Input voltage: AC 100-240 V
Operational conditions
Operating relative humidity (H-H): 10 - 93%
Operating temperature (T-T): -10 - 55 °C
Weight & dimensions
Weight: 2.51 kg
Package width: 451 mm
Package height: 425 mm
Width: 375 mm
Depth: 329.3 mm
Package depth: 147 mm
Package weight: 3.66 kg
Height: 53 mm
System requirements
Mobile operating systems supported: iOS, Android
Browser supported: Chrome; IE9+; Firefox
Performance
Output bandwidth: 180 / 256 Mbit/s
Playback modes: Instant playback, general playback, event playback, tag playback, smart playback
Recording modes: Motion detection, manual recording, smart recording, alarm
Operating system installed: Embedded LINUX
Video input channels: 8 channels
Input bandwidth: 180 / 256 Mbit/s
SMD Plus: Yes
Audio
Audio codecs: PCM; G711A; G711U; G726
Emergency call: Yes
Ports & interfaces
VGA (D-Sub) output ports: 1
USB 2.0 ports quantity: 2
HDMI ports quantity: 1
HDMI output: Yes
Audio RCA outputs: 1
Ethernet LAN data rates: 10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports: 1
PoE standard: IEEE 802.3af/at
PoE Port: 8*10/100Mbps
Video
Video codecs: Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
Maximum resolution (HDMI): 3840 x 2160 pixels
Hard drive
HDD interface: SATA
Maximum storage capacity: 16 TB
Number of SAS ports: 2
Safety warning
Warnings: The product must be disposed of properly in accordance with local regulations for the disposal of electronics., The appliance should be installed by a qualified professional., Do not expose the device to moisture or extreme temperatures.
