Technical details
Compliance certificates: CE
Processor
Built-in processor: Yes
Features
Rack mounting: Yes
On/off switch: Yes
Rack capacity: 1U
Product colour: Black
Power
Power over Ethernet (PoE) power per port: 25.5 W
Total Power over Ethernet (PoE) budget: 130 W
Power consumption (max): 10 W
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 10 - 93%
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Weight: 2.62 kg
Width: 375 mm
Depth: 329.6 mm
Package width: 451 mm
Package height: 425 mm
Package weight: 4.06 kg
Height: 53 mm
Package depth: 147 mm
System requirements
Browser supported: Chrome, IE, Safari, Edge, Firefox
Mobile operating systems supported: iOS, Android
Supported resolutions: 7680 x 4320, 3840 x 2160, 1920 x 1080, 1280 x 1024, 1280 x 720
Performance
Output bandwidth: 448 Mbit/s
Maximum frame rate: 30 fps
Input bandwidth: 448 Mbit/s
Audio formats supported: PCM, G.711u, G.726, G.711 A-law
Snapshot: Yes
Video motion detection: Yes
Backup function: Yes
Maximum resolution: 7680 x 4320 pixels
Alarm output channels: 2
Video loss detection: Yes
Video formats supported: H.264+, H.265, H.265+, MJPG, H.264
Alarm input channels: 4
Video input channels: 16 channels
Multi-screen: Yes
Operating system installed: Embedded LINUX
Face detection: Yes
People counting: Yes
Packaging content
Quick installation guide: Yes
Wireless LAN features
Wi-Fi: No
Ports & interfaces
HDMI output: Yes
Audio RCA outputs: 1
RS-485 ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
HDMI ports quantity: 1
Power over Ethernet (PoE): Yes
Audio RCA inputs: 1
USB 2.0 ports quantity: 1
RS-232 interface: Yes
Ethernet LAN data rates: 10, 100, 1000 Mbit/s
Power over Ethernet (PoE) ports quantity: 16
RS-232 ports: 1
Ethernet LAN (RJ-45) ports: 1
VGA (D-Sub) output ports: 1
Hard drive
Number of HDDs supported: 2
Maximum storage capacity: 20 TB
HDD interface: SATA
