Technical details
Compliance certificates: CE
Processor
Built-in processor: Yes
Features
Product colour: Black
Rack capacity: 1U
Rack mounting: Yes
On/off switch: Yes
Power
Output voltage: 12 V
Power consumption (max): 10 W
Output current: 4 A
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 10 - 93%
Weight & dimensions
Package width: 427 mm
Package weight: 2.77 kg
Width: 375 mm
Package height: 356 mm
Weight: 1.55 kg
Package depth: 137 mm
Depth: 284.8 mm
Height: 56 mm
System requirements
Browser supported: Chrome, IE, Safari, Edge, Firefox
Mobile operating systems supported: Android, iOS
Supported resolutions: 7680 x 4320, 3840 x 2160, 1920 x 1080, 1280 x 1024, 1280 x 720
Performance
Output bandwidth: 448 Mbit/s
Video motion detection: Yes
Maximum frame rate: 30 fps
Input bandwidth: 448 Mbit/s
Maximum resolution: 7680 x 4320 pixels
Multi-screen: Yes
Audio formats supported: G.726, G.711u, PCM, G.711 A-law
Video loss detection: Yes
Video formats supported: H.265+, H.265, H.264+, H.264
Video input channels: 16 channels
Snapshot: Yes
People counting: Yes
Face detection: Yes
Alarm output channels: 2
Alarm input channels: 4
Backup function: Yes
Operating system installed: Embedded LINUX
Packaging content
Quick installation guide: Yes
Wireless LAN features
Wi-Fi: No
Ports & interfaces
Audio RCA inputs: 1
VGA (D-Sub) output ports: 1
HDMI output: Yes
Audio RCA outputs: 1
HDMI ports quantity: 1
Ethernet LAN data rates: 100, 10, 1000 Mbit/s
RS-232 interface: Yes
USB 2.0 ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
DC-in jack: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
RS-232 ports: 1
RS-485 ports: 1
Hard drive
Maximum storage capacity: 20 TB
HDD interface: SATA
Number of HDDs supported: 2
