Processor
Processor cores: 2
Built-in processor: Yes
Features
Rack mounting: Yes
Product colour: Black
Rack capacity: 1U
Brand compatibility: Any brand
Power
AC input frequency: 47/63 Hz
AC input voltage: 100 - 240 V
Total Power over Ethernet (PoE) budget: 130 W
Power consumption (typical): 30 W
Power over Ethernet (PoE) power per port: 25.5 W
Operational conditions
Operating relative humidity (H-H): 10 - 93%
Operating temperature (T-T): -10 - 55 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Weight: 2.6 kg
Package weight: 3.8 kg
Height: 53 mm
Package width: 451 mm
Package depth: 425 mm
Width: 375 mm
Package height: 147 mm
Depth: 329.3 mm
System requirements
Mobile operating systems supported: Android, iOS
Supported resolutions: 1920x1080, 1280x1024, 1280x720, 1024x768
Performance
Number of motion detection zones: 396
Recording time: 120 min
Bit rate: 8192 Kbit/s
Split screen: Yes
Backup function: Yes
Maximum resolution: 1920 x 1080 pixels
On Screen Display (OSD): Yes
Recording modes: Manual, Schedule, Stop
Two-way talk: Yes
Playback controls: Yes
Video formats supported: M-JPEG, H.264
Alarm output channels: 2
Video input channels: 16 channels
PTZ control: Yes
Number of users: 128 user(s)
Video motion detection: Yes
Video loss detection: Yes
Snapshot: Yes
Alarm input channels: 4
Operating system installed: Embedded LINUX
Ports & interfaces
Power over Ethernet (PoE) ports quantity: 16
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
HDMI ports quantity: 1
USB 2.0 ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Power over Ethernet (PoE): Yes
Audio RCA inputs: 1
Networking standards: IEEE 802.3at, IEEE 802.3af
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
Internal SATA ports quantity: 2
HDMI output: Yes
Audio RCA outputs: 1
Supported network protocols: HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP
RS-232 interface: Yes
VGA (D-Sub) output ports: 1
Hard drive
Number of HDDs supported: 2
Maximum storage capacity: 16 TB
Safety warning
Warnings: Do not expose the device to moisture or extreme temperatures., The product must be disposed of properly in accordance with local regulations for the disposal of electronics., The appliance should be installed by a qualified professional.
