Power
Rated current: 4 A
DC input voltage: 12 V
Power consumption (typical): 10 W
Weight & dimensions
Package weight: 2.76 kg
Height: 53 mm
Package width: 433 mm
Width: 375 mm
Depth: 284 mm
Package depth: 141 mm
Weight: 1.51 kg
Package height: 366 mm
Supported resolutions: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
Performance
Audio formats supported: G.726, PCM, G.711 A-law, G.711 μ-law
Video input channels: 32 channels
Alarm output channels: 2
Alarm input channels: 4
Multi-screen: Yes
Maximum resolution: 3840 x 2160 pixels
Video formats supported: H.265, H.264+, H.264, H.265+
Storage
Number of HDDs supported: 2
Maximum storage capacity: 16 TB
HDD interface: SATA
Ports & interfaces
Audio RCA outputs: 1
VGA (D-Sub) output ports: 1
Audio RCA inputs: 1
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Ethernet LAN data rates: 10, 1000, 100
Internal SATA ports quantity: 2
USB 2.0 ports quantity: 2
Safety warning
Warnings: The product must be disposed of properly in accordance with local regulations for the disposal of electronics., The appliance should be installed by a qualified professional., Do not expose the device to moisture or extreme temperatures.
