Design
Product colour: Black, White
International Protection (IP) code: IP67
Display diagonal: 2.54 cm (1")
IK code: IK10
Form factor: Dome
Mounting type: Ceiling
Power
Power consumption (typical): 13 W
Power source type: DC, PoE
Power consumption (max): 22 W
DC output voltage: 24
DC output current: 2.5 A
Operational conditions
Operating temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Web-based management: Yes
Web browser: Yes
Weight & dimensions
Height: 332 mm
Diameter: 19 cm
Weight: 4.7 kg
Network
Ethernet LAN: Yes
Wi-Fi: No
Bluetooth: No
Certification: CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB, ANSI C63.4-2014
UL: UL60950-1+CAN/CSA C22.2, No.60950-1
Performance
Wide Dynamic Range (WDR): Yes
Type: IP security camera
PTZ modes: 5 Pattern
Connectivity technology: Wired
PTZ control: Yes
Auto-tracking: Yes
Placement supported: Indoor & outdoor
Packaging data
Package weight: 8 kg
Packaging content
Number of cameras: 1
Audio
Audio formats supported: G.711, G.729, G.722.1, G.726, G.723
Storage
Compatible memory cards: MicroSD (TransFlash)
Built-in HDD: No
Internal memory: 1000 MB
Maximum memory card size: 512 GB
ROM capacity: 4000 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Headphone outputs: 1
Camera
White balance: Outdoor, Indoor, Manual, Sodium lamp, Auto, Natural, Street lamp
Tilt angle range: 15 - 90°
Minimum illumination: 0.0005 lx
Pan range: 0 - 360°
Pan preset speed: 400 °/sec
Tilt preset speed: 300 °/sec
Camera pan control: Yes
Camera tilt control: Yes
Lens viewing angle, horizontal: 58.5–2.8
Lens viewing angle, diagonal: 67.5–3.2
Tilt manual speed: 0.1 - 200 °/sec
Pan manual speed: 0.1 - 300 °/sec
Lens viewing angle, vertical: 31.9–1.3
Image sensor
Progressive scan: Yes
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Sensor type: CMOS
Video
Back Light Compensation (BLC): Yes
Supported graphics resolutions: 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 1280 x 720 (HD 720), 2560 x 1440, 352 x 288, 704 x 576, 352 x 240, 704 x 480
Maximum resolution: 2560 x 1440 pixels
Total megapixels: 4 MP
Digital Wide Dynamic Range (DWDR): Yes
Noise reduction: Yes
Video compression formats: H.264H, H.264, H.264+, H.264B, H.265+, H.265
Noise reduction technology: 2D noise reduction, 3D noise reduction
Night vision
LED type: IR
Number of illumination LEDs: 4
Night vision distance: 150 m
Night vision: Yes
Lens system
Digital zoom: 16x
Focal length range: 4.8–154
Minimum aperture number: 1.6
Zoom capability: Yes
Optical zoom: 32x
Maximum aperture number: 4
Identify distance: 212 m
Closest focusing distance: 0.8 m
Observe distance: 839 m
Number of lenses: 1
Auto focus: Yes
Detect distance: 2124 m
Recognize distance: 425 m
Focus: Manual
Safety warning
Warnings: Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling., The product contains electronic components; do not dispose of with the normal household waste.
Panoramic camera
Digital Wide Dynamic Range (DWDR) (panoramic camera): Yes
