Processor
Built-in processor: Yes
Power
DC voltage: 12 V
Power supply type: DC
Power consumption (typical): 16 W
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): -10 - 55 °C
Weight & dimensions
Depth: 289.6 mm
Weight: 1.9 kg
Width: 375 mm
Height: 53 mm
Network
Ethernet LAN: Yes
Supported network protocols: HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; P2P
Wi-Fi: No
Mobile network connection: No
Ethernet LAN (RJ-45) ports: 1
Ethernet interface type: Fast Ethernet, Gigabit Ethernet
Mobile network generation: Not supported
Certification: CE-LVD: IEC 62368-1:2014
CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014
Performance
Dual stream support: Yes
Audio formats supported: PCM, G.711 A-law, G.711 μ-law
Multi-display modes: 9, 36, 16, 1, 25, 8, 4
Product colour: Black
Multi-display supported: Yes
Graphical user interface (GUI): Yes
Video motion detection: Yes
Operating system installed: Embedded LINUX
Video compression formats: H.264+, H.265, H.264, H.265+
Audio system: 2-way
Internal: No
Maximum video resolution: 3840 x 2160 pixels
Bit rate: 6144 Kbit/s
Packaging data
Package width: 427 mm
Package height: 356 mm
Package depth: 137 mm
Package weight: 3.24 kg
Ports & interfaces
Video input channels: 32 channels
USB 2.0 ports quantity: 1
BNC input ports: 32
RS-485 ports: 1
Line outputs (RCA): 1
VGA (D-Sub) output ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
HDMI ports quantity: 1
Line inputs (RCA): 1
Video
Video resolutions: 3840 x 2160, 1920 x 1080, 1280 x 720, 1280 x 1024
Hard drive
Maximum HDD capacity: 16 TB
Number of HDDs supported: 2
HDD interface: SATA
