Design
Housing material: Metal
Product colour: Black
Rack mounting: No
LED indicators: Yes
Reset button: Yes
Power
Redundant power supply (RPS) support: Yes
Power consumption (max): 110 W
DC input voltage: 54 V
Power source: DC/PoE
Power supply included: Yes
Input current: 2.22 A
Security
DHCP features: DHCP client
Operational conditions
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 5 - 95%
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
Switch layer: L2
Switch type: Managed
Cloud-managed: Yes
Weight & dimensions
Width: 190 mm
Weight: 550 g
Depth: 106 mm
Height: 30 mm
Network
Networking standards: IEEE 802.3x, IEEE 802.3af, IEEE 802.3bt, IEEE 802.3at, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab
Number of VLANs: 32
Flow control support: Yes
VLAN support: Yes
Copper ethernet cabling technology: 10BASE-T, 1000BASE-T, 100BASE-TX
Ethernet LAN data rates: 10,100,1000 Mbit/s
Virtual LAN features: Port-based VLAN
Spanning tree protocol: Yes
10G support: No
Packaging data
Package depth: 244 mm
Package height: 87 mm
Package weight: 1.3 kg
Package width: 256 mm
Certificates
Compliance certificates: CE
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 10
Gigabit Ethernet (copper) ports quantity: 10
Data transmission
Forwarding rate: 4.17 Mpps
Jumbo frames: 15000
Switching capacity: 20 Gbit/s
Jumbo frames support: Yes
MAC address table: 8000 entries
Packet buffer memory: 0.5 MB
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) ports quantity: 8
Safety warning
Warnings: Do not open the case or try to repair it yourself., The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations., Ensure the unit is adequately ventilated during operation.
Sustainability
Sustainability compliance: Yes
