Design Product colour: White Form factor: Bullet Housing material: Metal Mounting type: Ceiling/Wall/Pole
Power DC output voltage: 12 Power source type: DC
Security Mirror: Yes Video motion detection: Yes
Operational conditions Operating temperature (T-T): -40 - 60 °C Storage temperature (T-T): -40 - 60 °C Operating relative humidity (H-H): 0 - 95%
Weight & dimensions Weight: 650 g Width: 240.7 mm Height: 90.4 mm Depth: 90.7 mm
Network Ethernet LAN: Yes Wi-Fi: No Bluetooth: No Ethernet interface type: Fast Ethernet
Performance Wide Dynamic Range (WDR): Yes Connectivity technology: Wired Type: CCTV security camera Day/night mode: Yes Dynamic range: 65 dB Placement supported: Indoor & outdoor
Packaging content Number of cameras: 1
Storage Built-in HDD: No Compatible memory cards: MicroSD (TransFlash)
Ports & interfaces BNC output ports: 1
Camera Pan range: 0 - 360° Minimum illumination: 0.002 lx Tilt angle range: 0 - 90° Camera shutter speed: 1/25 s–1/100,000 Camera shutter type: Electronic Angle of rotation: 360°
Image sensor Progressive scan: Yes Optical sensor size: 25.4 / 2.8 mm (1 / 2.8") Sensor type: CMOS Effective sensor resolution: 2 pixels Number of effective pixels (H x V): 1920 x 1080 pixels Number of sensors: 1
Video Highlight Compensation (HLC): Yes Supported graphics resolutions: 1920 x 1080 (HD 1080), 960 x 480, 960 x 576 Maximum resolution: 1920 x 1080 pixels Back Light Compensation (BLC): Yes Supported video modes: 1080p Total megapixels: 2 MP Frame rate: 30 fps Digital Wide Dynamic Range (DWDR): Yes Noise reduction: Yes Region of Interest (ROI) encoding: Yes Noise reduction technology: 3D noise reduction Video streaming: Yes Privacy masking: Yes Gain control type: Auto/Manual
Night vision Night vision: Yes
Lens system Identify distance: 11 m Recognize distance: 22.1 m Observe distance: 44.1 m Maximum aperture number: 1.6 Detect distance: 110.3 m Number of lenses: 4
Safety warning Warnings: Start up and operate the unit in accordance with the operating instructions to avoid the risk of electric shock., Avoid exposure of the device to direct water or moisture., It is forbidden to open the device yourself; service and repairs should be performed by qualified personnel.
