Technical details Compliance certificates: Federal Communications Commission (FCC)
Power AC input frequency: 47 - 63 Hz AC input voltage: 100 - 240 V
Operational conditions Operating relative humidity (H-H): 10 - 39% Operating temperature (T-T): -10 - 55 °C Storage temperature (T-T): -20 - 60 °C
Weight & dimensions Package width: 451 mm Weight: 2.66 kg Width: 375 mm Package depth: 147 mm Depth: 329.3 mm Package weight: 3.82 kg Height: 53 mm Package height: 425 mm
Performance Maximum resolution: 3840 x 2160 pixels Video formats supported: H.264, H.265, H.265+, H.264+ Face detection: Yes Audio formats supported: PCM, G.711u Alarm output channels: 2 Image formats supported: MJPEG Video input channels: 16 channels Alarm input channels: 4
Ports & interfaces Ethernet LAN (RJ-45) ports: 1 RS-485 ports: 1 USB 2.0 ports quantity: 1 HDMI ports quantity: 1 USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1 Power over Ethernet (PoE) ports quantity: 16 Power over Ethernet (PoE): Yes VGA (D-Sub) output ports: 1 RS-232 interface: Yes
