Technical details
Lens mount interface: M12
Iris: Yes
Design
International Protection (IP) code: IP67
Protection features: Waterproof, Corrosion resistant
Form factor: Bullet
Housing material: Metal, Plastic
Product colour: Black, White
Mounting type: Ceiling/Wall/Pole
Power
Power source type: DC
DC output voltage: 12
Power consumption (max): 7.2 W
Security
Mirror: Yes
Detection distance: 88 m
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -40 - 60 °C
Storage relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -40 - 60 °C
Weight & dimensions
Length: 198.4 mm
Weight: 320 g
Height: 76.2 mm
Width: 80.2 mm
Network
Wi-Fi: No
Ethernet LAN: No
Bluetooth: No
Performance
Type: CCTV security camera
Placement supported: Indoor & outdoor
Connectivity technology: Wired
Built-in light: Yes
Maximum operating distance: 88 m
Infrared (IR) cut-off filter: Yes
Day/night mode: Yes
Wide Dynamic Range (WDR): Yes
Packaging data
Package weight: 490 g
Packaging content
Number of cameras: 1
Audio
Built-in microphone: Yes
Signal-to-Noise Ratio (SNR): 65 dB
Storage
Built-in HDD: No
Camera
Camera shutter speed: 1/25 - 1/100000 s
Camera shutter type: Electronic
Lens viewing angle, vertical: 56.5°
White balance: Auto
Camera tilt control: Yes
Angle of rotation: 360°
Tilt angle range: 0 - 90°
Camera pan control: Yes
Minimum illumination: 0 lx
Pan range: 0 - 360°
Lens viewing angle, horizontal: 105.5°
Lens viewing angle, diagonal: 125.3°
Image sensor
Sensor type: CMOS
Progressive scan: Yes
Video
Gain control type: Auto
Noise reduction: Yes
Smart IR: Yes
Noise reduction technology: 3D noise reduction
Analog signal format system: PAL, NTSC
Frame rate: 15 fps
Supported graphics resolutions: 3840 x 2160, 960 x 576, 960 x 480
Maximum resolution: 3840 x 2160 pixels
Back Light Compensation (BLC): Yes
Highlight Compensation (HLC): Yes
Night vision
Number of illumination LEDs: 4
Night vision distance: 40 m
LED type: IR/White
Night vision: Yes
Lens system
Observe distance: 35.2 m
Closest focusing distance: 1.3 m
Fixed focus: Yes
Detect distance: 88 m
Fixed focal length: 2.8 mm
Recognize distance: 17.6 m
Maximum aperture number: 2
Identify distance: 8.8 m
Sustainability
Compliance certificates: Low Voltage Directive (LVD), CE, Electromagnetic Compatibility (EMC)
