Design Product colour: White Form factor: Dome Mounting type: Ceiling/wall International Protection (IP) code: IP67 Housing material: Plastic
Power Power consumption (max): 4.1 W DC output voltage: 12 Power source type: DC
Security Video motion detection: Yes Mirror: Yes
Operational conditions Storage temperature (T-T): -40 - 60 °C Operating temperature (T-T): -40 - 60 °C Operating relative humidity (H-H): 0 - 95% Storage relative humidity (H-H): 0 - 95%
Weight & dimensions Weight: 190 g Diameter: 9.74 cm Height: 92.9 mm Certification: CE-LVD: EN 62368-1;
CE-EMC: EN 55032; EN 55035;
Performance Wide Dynamic Range (WDR): Yes Day/night mode: Yes Placement supported: Indoor & outdoor Alarm input/output: Yes Remote viewing: Yes Built-in light: Yes Connectivity technology: Wired Type: IP security camera
Packaging data Package weight: 260 g
Packaging content Number of cameras: 1 Manual: Yes
Audio Built-in microphone: Yes Signal-to-Noise Ratio (SNR): 65 dB
Storage Built-in HDD: No
Camera Tilt angle range: 0 - 78° Angle of rotation: 360° Minimum illumination: 0.01 lx Camera shutter type: Electronic White balance: Auto, Area white balance Number of Privacy masking areas: 8 Lens viewing angle, horizontal: 105.5° Lens viewing angle, diagonal: 125.3° Lens viewing angle, vertical: 56.5° Camera shutter speed: 1/100000 s Pan range: 0 - 360°
Image sensor Sensor type: CMOS Number of sensors: 1 Progressive scan: Yes
Video Highlight Compensation (HLC): Yes Supported graphics resolutions: 960 x 576, 3840 x 2160, 960 x 480 Total megapixels: 5 MP Back Light Compensation (BLC): Yes Digital Wide Dynamic Range (DWDR): Yes Maximum resolution: 3840 x 2160 pixels Gain control type: Auto/Manual Noise reduction: Yes Frame rate: 15 fps Noise reduction technology: 3D noise reduction Smart IR: Yes
Night vision Night vision distance: 30 m Number of illumination LEDs: 2 Night vision: Yes
Lens system Number of lenses: 1 Identify distance: 8.8 m Fixed focus: Yes Observe distance: 35.2 m Focus: Motorized/Manual Fixed focal length: 2.8 mm Recognize distance: 17.6 m Detect distance: 88 m Maximum aperture number: 2
